HPE Aruba Networking AP-514 (RW) TAA Dual Radio 4x4/2x2 802.11ax Ext Antennas Unified Campus AP
HPE Aruba Networking AP-514 (RW) TAA Dual Radio 4x4/2x2 802.11ax Ext Antennas Unified Campus AP
HPE Aruba Networking AP-514 (RW) TAA Dual Radio 4x4/2x2 802.11ax Ext Antennas Unified Campus AP
HPE Aruba Networking AP-514 (RW) TAA Dual Radio 4x4/2x2 802.11ax Ext Antennas Unified Campus AP

HPE Aruba Networking AP-514 (RW) TAA Dual Radio 4x4/2x2 802.11ax Ext Antennas Unified Campus AP

Hewlett Packard Enterprise
£1,249.99
Stock Available: 0
  • 2.4 GHz 575 Mbit/s
  • 5 GHz 4800 Mbit/s
  • Maximum data transfer rate: 5375 Mbit/s
  • IEEE 802.11ax
  • WMM, WPA, WPA2
  • Power over Ethernet (PoE)
  • External

The HPE Aruba Networking 510 Series Campus Access Points deliver Wi-Fi 6 coverage ideal for office spaces, training and meeting facilities, and hospitals. With 2.69 Gbps maximum combined data rate, multi-gigabit Ethernet for fast wired connectivity, and built-in IoT radio, the 510 Series delivers reliable, high-performance Wi-Fi Wi-Fi CERTIFIED™ for medium density campus environments. These APs can be deployed using Zero Touch Provisioning (ZTP) for ease of implementation at remote locations. It is Wi-Fi and supports 802.11ax features: OFDMA for multi-user efficiency, target wake time (TWT) to extend the battery life of connected IoT devices, and WPA3 and Enhanced Open for greater password and guest security. The 510 Series includes a limited lifetime warranty.

What is new supporting point:
Dynamic Segmentation and policy enforcement firewalls automatically enforce consistent policies across wired and wireless networks, enhancing user and device security.
Offered in optional eco-friendly 10-packs.
Wi-Fi 6 AP that provides up to 2.69 Gbps maximum combined data rate.
Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
IoT-ready with [1] Bluetooth 5 and Zigbee support and fast wired connections with 2.5 Gbps Ethernet and 1 Gbps Ethernet ports.
Client and RF optimization to match clients with one of the best available AP and reduce coverage gaps.

Features
Modulation 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Spread spectrum method DSSS, OFDM
MIMO Yes
Auto MDI/MDI-X Yes
Networking standards IEEE 802.11ax
Ethernet LAN data rates 100,1000,2500 Mbit/s
Maximum data transfer rate (5 GHz) 4800 Mbit/s
Maximum data transfer rate (2.4 GHz) 575 Mbit/s
Maximum data transfer rate 5375 Mbit/s
5 GHz Yes
2.4 GHz Yes
Security
Security algorithms WMM, WPA, WPA2
Ports & interfaces
DC-in jack Yes
USB connector type USB Type-A
USB 2.0 ports quantity 1
Ethernet LAN (RJ-45) ports 2
Power
Power consumption (typical) 16 W
Power over Ethernet (PoE) Yes
Design
Cable lock slot type Kensington
Cable lock slot Yes
Product colour White
Placement Ceiling
Antenna
Number of connectors 4
Antenna connector type RP-SMA
Antenna type External
General
Product family Aruba Networking
Certificates
Certification None
Compliance certificates Low Voltage Directive (LVD)
Weight & dimensions
Weight 810 g
Height 46 mm
Depth 200 mm
Width 200 mm
Operational conditions
Storage relative humidity (H-H) 5 - 93%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 50 °C
Operating relative humidity (H-H) 5 - 93%
