HPE Aruba Networking AP-503R (RW) Dual Radio 2x2 802.11ax Wi-Fi 6 Remote Access Point
Couldn't load pickup availability
- 2.4 GHz 574 Mbit/s
- 5 GHz 1200 Mbit/s
- Maximum data transfer rate: 1490 Mbit/s
- IEEE 802.11ax
- WMM, WPA, WPA2, WPA3
- Antennas quantity: 2 Internal Integrated antenna
HPE Aruba Networking 500R Series Remote Access Points enable IT teams to deliver cost-effective Wi-Fi 6 coverage in a compact desktop form factor that is ideal for small branches and remote work. With 1.49 Gbps maximum combined speed, Zero Touch Provisioning, wired ports, and optional USB LTE modem, the 500R Series makes it easier to extend the workplace experience anywhere that has an internet or cellular connection. The 500R Series is Wi-Fi CERTIFIED™ and includes support for all 802.11ax features: OFDMA for multi-user efficiency, target wake time (TWT) to extend the battery life of connected IoT devices, and WPA3 and Enhanced Open for greater password and guest security. The 500R Series includes a limited lifetime warranty.
What is new supporting point:
Managed through cloud-native HPE Aruba Networking Central to extend the WAN to home offices, small offices, and even temporary locations.
Cost-effective Wi-Fi 6 remote access points that provide up to 1.49 Gbps maximum combined data rate in a desktop form factor ideal for teleworker or small branch environments.
Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
Wired and wireless connections that include encryption and use authentication to protect the remote network.
Optional USB LTE modem that supports high speed LTE Cat 12 connectivity for cellular backhaul.
Zero Touch Provisioning that provides ease of implementation in branch offices and remote sites, without on-site technical expertise.
| Features | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Spread spectrum method | DSSS, OFDM, OFDMA |
| MIMO | Yes |
| Auto MDI/MDI-X | Yes |
| Networking standards | IEEE 802.11ax |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1200 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate | 1490 Mbit/s |
| 5 GHz | Yes |
| 6 GHz | No |
| 2.4 GHz | Yes |
| Security | |
|---|---|
| Security algorithms | WMM, WPA, WPA2, WPA3 |
| Ports & interfaces | |
|---|---|
| USB connector type | Micro-USB B, USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
|---|---|
| Power supply | 18 W |
| Power consumption (max) | 15.4 W |
| DC voltage range | 12 V |
| Power over Ethernet (PoE) | No |
| Design | |
|---|---|
| LED indicators | Reset, Status, System |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Product colour | White |
| Placement | Desk, Wall |
| Antenna | |
|---|---|
| Antenna gain level (max) | 5.1 dBi |
| Antennas quantity | 2 |
| Antenna features | Integrated antenna |
| Antenna direction type | Omni-directional |
| Antenna type | Internal |
| General | |
|---|---|
| Product family | Aruba Networking |
| Certificates | |
|---|---|
| Certification | None |
| Compliance certificates | Low Voltage Directive (LVD) |
| Weight & dimensions | |
|---|---|
| Weight | 320 g |
| Height | 39 mm |
| Depth | 150 mm |
| Width | 150 mm |
| Packaging data | |
|---|---|
| Package weight | 600 g |
| Package height | 50 mm |
| Package depth | 170 mm |
| Package width | 240 mm |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 10 - 100% |
| Storage temperature (T-T) | -25 - 55 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
