HPE 843189-B21 network equipment chassis 16U
£170,687.99
Couldn't load pickup availability
- Rack mounting 16U
- Cooling type: Active
- Number of power supply units: 6
Mellanox InfiniBand (IB) EDR Modular Switches are supported to work with HPE InfiniBand Adapters to deliver high performance connectivity for HPC clusters using HPE ProLiant XL and DL Server families. The Modular switches feature the Mellanox Switch-B™ 2 ASIC, and include three chassis with 216 ports, 324 ports, and 648 ports, respectively.
The Mellanox InfiniBand EDR Switch is ideally suited for customers who deploy high-performance clusters based on HPE ProLiant XL and DL Servers using InfiniBand technology.
| Technical details | |
|---|---|
| Number of slots | 9 |
| Throughput | 64 Tbps |
| Latency | ≤ 0.5 μs |
| Ports quantity | 324 |
| Compliance certificates | RoHS |
| Supported protocols | IBTA 1.2.1 & 1.3 |
| Cooling type | Active |
| Rack capacity | 16U |
| Rack mounting | Yes |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Power | |
|---|---|
| Number of power supply units | 6 |
| Weight & dimensions | |
|---|---|
| Weight | 238 kg |
| Width | 482.6 mm |
| Depth | 761.2 mm |
| Height | 770.3 mm |
