HP Intel Xeon E5-2637 v3 processor 3.5 GHz 15 MB L3
£1,316.99
Couldn't load pickup availability
- Intel Xeon E5 v3 E5-2637V3 3.5 GHz
- 15 MB L3 LGA 2011-v3
- Processor cores: 4 22 nm 64-bit 135 W
- Maximum internal memory supported by processor: 768 GB DDR4-SDRAM
Options, accessories, services and support for all your HP and Compaq products.
| Processor | |
|---|---|
| Processor family | Intel Xeon E5 v3 |
| Processor model | E5-2637V3 |
| Processor base frequency | 3.5 GHz |
| Processor cores | 4 |
| Processor socket | LGA 2011-v3 |
| Processor lithography | 22 nm |
| Component for | Server/workstation |
| Processor threads | 8 |
| System bus rate | 9.6 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.7 GHz |
| Processor cache | 15 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 135 W |
| VID Voltage Range | 0.65 - 1.3 V |
| Stepping | R2 |
| Bus type | QPI |
| Number of QPI links | 2 |
| Memory bandwidth supported by processor (max) | 68 GB/s |
| Memory | |
|---|---|
| Maximum internal memory supported by processor | 768 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Memory channels | Quad-channel |
| ECC | Yes |
| Graphics | |
|---|---|
| On-board graphics card | No |
| Features | |
|---|---|
| Thermal Monitoring Technologies | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 40 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX 2.0 |
| Physical Address Extension (PAE) | Yes |
| CPU configuration (max) | 2 |
| Embedded options available | No |
| Scalability | 2S |
| Processor special features | |
|---|---|
| Intel Flex Memory Access | No |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel Demand Based Switching | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel TSX-NI | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel 64 | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Operational conditions | |
|---|---|
| Tcase | 76.6 °C |
| Other features | |
|---|---|
| Compatibility | DL360 Gen9 |
