Hikvision DS-D5AC12T7-16S5 video wall processor Black 95 W
iFrame
£1,342.99
Couldn't load pickup availability
- Intel UHD Graphics for 12th Gen Intel Processors, support 4K resolution
- Support M.2 nvme system disk quick start
- Support 4 USB 3.0 ports, 2 USB2.0 ports, 1 HDMI port, 1 DP interface，1 Type-C port
- Support Wi-Fi IEEE 802.11 a/b/g/n/ac/ax (Wi-Fi 6)
- Support TPM 2.0
| Design | |
|---|---|
| Rack mounting | Yes |
| Fan location | Top |
| Number of fans | 1 fan(s) |
| Built-in fan | Yes |
| Built-in display | No |
| Product colour | Black |
| Features | |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Operating system installed | Windows 11 Enterprise |
| Internal memory | 16 GB |
| Internal storage capacity | 512 GB |
| Processor frequency | 2.3 GHz |
| Processor cores | 10 |
| Built-in processor | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN | Yes |
| Ports & interfaces | |
|---|---|
| 3.5 mm connector | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 4 |
| USB 2.0 Type-A ports quantity | 2 |
| RJ-45 ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| HDMI version | 1.4 |
| HDMI output ports quantity | 1 |
| Power | |
|---|---|
| Input voltage | 12 - 19 V |
| Power consumption (max) | 95 W |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 10 - 90% |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Package type | Box |
| Package weight | 1.36 kg |
| Package height | 80 mm |
| Package depth | 278 mm |
| Package width | 308 mm |
| Weight | 1.22 kg |
| Height | 30 mm |
| Depth | 180 mm |
| Width | 195 mm |
