Overview
X3D Turbo Mode: Unleash new era gaming performance
DDR5 OC up to 8200MT/s, dual Channel DDR5
AMD Socket AM5: Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
Digital twin 14+2+2 phases VRM solution
M.2 EZ-Flex: high-efficiency heat dissipation & flexible baseplate for M.2 SSD(Exclusive Patented Design)
WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
EZ-Latch Plus: PCIe and M.2 slots with Quick Release & Screwless Design
EZ-Latch Click: M.2 heatsinks with screwless design
Ultra-Fast Storage: 4*M.2 slots, including PCIe 5.0 x4
Efficient Thermal: VRM Thermal Armor Advanced & M.2 Thermal Guard L & M.2 Thermal Guard Ext
Fast Networking: 5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge technology.
Specifications
Processor Processor manufacturer AMD Processor socket Socket AM5 Compatible processor series AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series Supported processor sockets Socket AM5
Memory Supported memory types DDR5-SDRAM Number of memory slots 4 Memory slots type DIMM Memory channels Dual-channel ECC сompatibility Non-ECC Supported memory clock speeds 8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz Supported memory clock speed (max) 8200 MHz Maximum internal memory 256 GB Unbuffered memory Yes Maximum internal memory per slot 64 GB
Show all 108 specifications Show fewer specifications Storage controllers Supported storage drive types HDD & SSD Supported storage drive interfaces M.2, PCI Express 4.0, PCI Express 5.0, SATA III Number of storage drives supported 6 Number of HDDs supported 2 RAID support Yes RAID levels 0, 1, 5, 10
Graphics Parallel processing technology support Not supported On-board graphics card No Maximum resolution 4096 x 2160 pixels HDCP Yes DirectX version 12.0
Internal I/O USB 2.0 connectors 2 USB 3.2 Gen 1 (3.1 Gen 1) connectors 1 USB 3.2 Gen 2x2 connectors 1 Number of SATA III connectors 2 Front panel audio connector Yes Front panel connector Yes ATX Power connector (24-pin) Yes CPU fan connector Yes Number of CPU fan connectors 2 Number of chassis fan connectors 6 Peripheral (Molex) power connectors (4-pin) 1 EPS power connector (8-pin) Yes Number of EPS power connectors (8-pin) 1 Number of noise detection headers 1 Number of temperature sensor headers 2 Number of water pump connectors 3 12V power connector Yes TPM connector Yes RGB LED pin header Yes Number of RGB LED pin headers 4
Rear panel I/O ports USB 2.0 ports quantity 4 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2 USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 Ethernet LAN (RJ-45) ports 1 HDMI ports quantity 1 HDMI version 2.1 Line-in Yes Headphone outputs 1 S/PDIF out port Yes Digital audio optical out 1 WiFi-AP antenna jack 2
Network Ethernet LAN Yes Ethernet interface type 5 Gigabit Ethernet LAN controller Realtek RTL8126 Wi-Fi Yes Top Wi-Fi standard Wi-Fi 7 (802.11be) Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) WLAN controller model Realtek RTL8922AE Bluetooth Yes Bluetooth version 5.4
Features Component for PC Motherboard form factor ATX Motherboard chipset family AMD Motherboard chipset AMD B850 Audio chip Realtek ALC897 Audio output channels 7.1 channels Product colour White PC health monitoring Fan, Temperature, Voltage, Water cooling Cooling type Passive Power source type ATX Windows operating systems supported Windows 11 x64
Expansion slots PCI Express x16 (Gen 4.x) slots 1 PCI Express x16 (Gen 5.x) slots 1 Number of M.2 (M) slots 4 1st M.2 largest key size 25110 1st M.2 highest PCI Express generation 5.0 2nd M.2 largest key size 22110 2nd M.2 highest PCI Express generation 5.0 3rd M.2 largest key size 22110 3rd M.2 highest PCI Express generation 4.0 4th M.2 largest key size 22110 4th M.2 highest PCI Express generation 4.0
BIOS BIOS type UEFI AMI BIOS memory size 512 Mbit ACPI version 5.0 Clear CMOS jumper Yes Desktop Management Interface (DMI) version 2.7 System Management BIOS (SMBIOS) version 2.7
Battery Lithium weight per battery 0.07 g Battery weight 3 g Number of battery cells 1 Battery technology Lithium-Manganese Dioxide (LiMnO2) Battery type CR2032
Weight & dimensions Width 305 mm Depth 244 mm Height 35 mm
Packaging content Batteries included Yes Screws included Yes Antenna included Yes Bundled software Norton® Internet Security (OEM version)
