DrayTek V2767VAX-K wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
£276.99
Couldn't load pickup availability
- VDSL2 or 2.5Gb Ethernet Router with Failover
- Integrated VoIP gateway with dual FXS phone ports
- 1x 2.5 Gigabit RJ-45 switchable WAN/LAN Port
- 3x Gigabit RJ-45 LAN Ports
- In total 4 (3+1) LAN ports (1 is the WAN/LAN switchable)
- Up to 2.3Gbps Firewall Throughput
- Up to 300Mbps IPsec VPN Throughput
- 16x LAN-to-LAN & Remote Teleworker VPN Tunnels
- AX3000 – Wi-Fi 6 Dual Band Wireless (‘ax’ models)
- SPI Firewall and Content Filtering
- Compatible with VigorACS central management platform
High-Performance VDSL, Wi-Fi 6 and VoIP Connectivity for SMEs
The DrayTek Vigor 2767Vax combines high-speed VDSL and full fibre connectivity, AX3000 Wi-Fi 6 wireless, integrated VoIP telephony and advanced business networking features in a single device. Designed for home offices, small businesses and distributed teams, it delivers secure internet access, business-grade VPN connectivity, integrated SIP telephony through two FXS ports, and up to 2.3Gbps firewall throughput for modern communications and cloud-based applications.
| WAN connection | |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | Yes |
| SIM card slot | No |
| 3G/4G USB modem compatibility | Yes |
| WAN connection type | RJ-11, RJ-45, USB |
| Wireless LAN features | |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 3000 Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Cabling technology | 10/100/1000/2500Base-T |
| Full duplex | Yes |
| Flow control support | Yes |
| Multicast support | Yes |
| Port triggering | Yes |
| Port forwarding | Yes |
| Load balancing system | Yes |
| Dynamic DNS (DDNS) | Yes |
| Policy-based routing | Yes |
| SSID-based VLAN assignment | Yes |
| Static route | Yes |
| Number of guest networks (5 GHz) | 8 |
| Number of guest networks (2.4 GHz) | 8 |
| Wireless Distribution System (WDS) bridge | Yes |
| VPN tunnels quantity | 16 |
| Internet connection backup | Yes |
| VPN Passthrough | Yes |
| VPN support | IPsec IKEv1, IKEv2, IKEv2 EAP IPsec-XAuth OpenVPN WireGuard EasyVPN - New! |
| DSL features | |
|---|---|
| ADSL2+ | Yes |
| VDSL2 | Yes |
| Internal modem | Yes |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | Yes |
| USB 2.0 ports quantity | 2 |
| RJ-11 ports quantity | 1 |
| DC-in jack | Yes |
| Management features | |
|---|---|
| Web-based management | Yes |
| Web-based setup wizard | Yes |
| Bandwidth control | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Quality of Service (QoS) support | Yes |
| Wake-on-LAN ready | Yes |
| Reset button | Yes |
| Intelligent Mesh technology | Yes |
| WPS push button | Yes |
| MIMO | Yes |
| MU-MIMO technology | Yes |
| Security | |
|---|---|
| Security algorithms | 3DES, AES, SSH, HTTPS, IPSec, WPA2-Enterprise, DES, OWE, WPA2-Personal, WEP, WPA3-Enterprise, WPA3-Personal, WPA-Enterprise, WPA-Personal |
| Firewall | Yes |
| Access Control List (ACL) | Yes |
| Guest access | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Schedule access | Yes |
| DDoS protection | Yes |
| Parental control | Yes |
| DoS attack prevention | Yes |
| Filtering | Yes |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| URL filtering | Yes |
| System event log | Yes |
| IGMP snooping | Yes |
| DMZ support | Yes |
| Network address translation (NAT) | Yes |
| Protocols | |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6 |
| Routing protocols | BGP, RIPng, RIP-1, OSPF, RIP-2 |
| Design | |
|---|---|
| Product type | Tabletop router |
| Product colour | White |
| Housing material | Plastic |
| Wall mountable | Yes |
| LED indicators | DSL, LAN, Power, USB |
| On/off switch | Yes |
| Packaging content | |
|---|---|
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Antenna included | Yes |
| Quick start guide | Yes |
| Antenna | |
|---|---|
| Antenna design | Internal & external |
| Detachable antenna(s) | Yes |
| Features | |
|---|---|
| Languages support | English |
| Operating system installed | DrayOS 5 |
| Firmware upgradeable | Yes |
| Power | |
|---|---|
| Power consumption (typical) | 22.1 W |
| External power adapter | Yes |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 665 g |
| Height | 42 mm |
| Depth | 131 mm |
| Width | 207 mm |
| Logistics data | |
|---|---|
| Warranty period | 2 year(s) |
| Country of origin | Taiwan |
