DELL
£8,274.99
Stock Available: 0
  • No OS
  • Intel Xeon 6 6507P (48MB Cache, 3.5GHz)
  • 32GB DDR5-SDRAM (1 x 32) & 480GB SSD
  • iDRAC10, Enterprise 17G

Simple, Scalable and Efficient solutions
The 1U, one-socket PowerEdge R470 is tailored to help you reach your budgetary requirements with optimised power and balance performance in your data center.

Processor
Processor threads 16
Memory types supported by processor DDR5-SDRAM
Memory clock speeds supported by processor 6400 MHz
System bus rate 24 GT/s
Thermal Design Power (TDP) 150 W
Number of processors installed 1
Processor cache 48 MB
Processor cores 8
Processor frequency 3.5 GHz
Processor model 6507P
Processor family Intel Xeon 6
Processor manufacturer Intel
Memory
Memory slots 16x DIMM
Memory layout (slots x size) 1 x 32 GB
Memory ranking 2
Buffered memory type Registered (buffered)
Internal memory type DDR5-SDRAM
Internal memory 32 GB
Storage
Drive writes per day (DWPD) 1
Optical drive type No
Hot-Plug support Yes
Supported RAID controllers PERC H965i Controller, Front, DC-MHS
RAID support Yes
Number of SSDs supported 8
SSD size 2.5"
Supported SSD sizes 2.5"
SSD interface SATA III
SSD capacity 480 GB
Number of SSDs installed 1
Total storage capacity 480 GB
Ports & interfaces
VGA (D-Sub) ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
Ethernet LAN (RJ-45) ports 1
Expansion slots
PCI Express x16 (Gen 5.x) slots 2
Design
Bezel Yes
Product colour Black
Chassis type Rack (1U)
Performance
Remote administration iDRAC10, Enterprise 17G
Software
Compatible operating systems Canonical Ubuntu Server LTS RedHat Enterprise LinuxSUSE Linux Enterprise ServerVMware ESXiWindows ServerWindows Server Datacenter
Operating system installed No
Power
Power supply input voltage 100 - 240 V
Number of redundant power supplies installed 2
Power supply 1100 W
Redundant power supply (RPS) support Yes
Certificates
80 PLUS certification 80 PLUS Titanium
General
Product family PowerEdge
Carbon footprint
Total carbon footprint (kg of CO2e) 2549
Total carbon emissions, standard deviation (kg of CO2e) 1827
Carbon emissions, manufacturing (kg of CO2e) 553.133
Carbon emissions, logistics (kg of CO2e) 170.783
Carbon emissions, energy usage (kg of CO2e) 1799.594
Carbon emissions, end-of-life (kg of CO2e) 22.941
PAIA version PAIA 1.4.2, 2025
Weight & dimensions
Height 42.8 mm
Width 482 mm
Packaging content
Packaging content 2x Rack Power Cord 2M (C13/C14 12A) - FGA OnlyReadyRails Sliding Rails Without Cable Management Arm or Strain Relief Bar,Riser Config 6
Other features
Open Compute Project (OCP) 1x16 Onboard OCP
Target workload Read Intensive (RI)
Data transfer rate 6 Gbit/s
Bytes per sector 512e
