Cisco Intel Xeon Gold 6416H processor 2.2 GHz 45 MB
£4,128.99
Couldn't load pickup availability
- Intel® Xeon® Gold 6416H 2.2 GHz
- 45 MB LGA 4677 (Socket E)
- Processor cores: 18 10 nm 64-bit 165 W
- Maximum internal memory supported by processor: 4 TB DDR4-SDRAM
The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® Gold |
| Processor generation | Intel Xeon Scalable 4th Gen |
| Processor model | 6416H |
| Processor base frequency | 2.2 GHz |
| Processor cores | 18 |
| Processor socket | LGA 4677 (Socket E) |
| Processor lithography | 10 nm |
| Processor series | Intel Xeon Gold 6000 Series |
| Processor threads | 36 |
| System bus rate | 16 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.2 GHz |
| High priority cores | 6 |
| High priority core frequency | 2.4 GHz |
| Low priority cores | 12 |
| Low priority core frequency | 2 GHz |
| Processor cache | 45 MB |
| Thermal Design Power (TDP) | 165 W |
| Stepping | S3 |
| Processor codename | Sapphire Rapids |
| Memory | |
|---|---|
| Maximum internal memory supported by processor | 4 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory channels | Octa-channel |
| ECC | Yes |
| Graphics | |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Features | |
|---|---|
| Execute Disable Bit | Yes |
| Market segment | Server |
| Use conditions | Server/Enterprise |
| Maximum number of PCI Express lanes | 80 |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AMX, AVX, AVX 2.0, AVX-512, SSE4.2 |
| Embedded options available | No |
| Scalability | S4S |
| Processor special features | |
|---|---|
| Intel® Speed Shift Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0 | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Maximum Enclave Size Support for Intel® SGX | 512 GB |
| Intel® Platform Firmware Resilience Support | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Boot Guard | Yes |
| Intel® OS Guard | Yes |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel 64 | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel® On Demand Feature Activation | Yes |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® In-memory Analytics Accelerator (IAA) | 1 default devices |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Operational conditions | |
|---|---|
| DTS Max | 95 °C |
| Tcase | 82 °C |
| Technical details | |
|---|---|
| Number of UPI links | 3 |
