Cisco · MPN: C9200CX-8UXG-2XH-A
£3,364.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £1,121.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Managed L2/L3
  • Quality of Service (QoS) support
  • 10G support
  • MAC address table: 32000 entries Switching capacity: 128 Gbit/s
  • Access Control List (ACL)
  • Rack mounting Stackable
  • AC Power supply included Power over Ethernet (PoE)

Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.

As foundational building blocks for the Cisco Digital Network Architecture, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.

Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE® and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.

With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry’s unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access. Catalyst 9200 Series switches also provide operational choice of Cisco DNA Center, or cloud monitoring for Catalyst on Meraki dashboard.

Specifications

Management features

Switch typeManaged
Switch layerL2/L3
Quality of Service (QoS) supportYes
MIB supportY

Ports & interfaces

Installed SFP+ modules quantity2
USB 2.0 ports quantity1
Compatible memory cardsSD
Show all 39 specificationsShow fewer specifications

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportYes
Full duplexYes
VLAN supportYes
Number of VLANs4096

Data transmission

MAC address table32000 entries
Switching capacity128 Gbit/s
Forwarding rate95.23 Mpps
Jumbo frames supportYes
Jumbo frames9198
Packet buffer memory6 MB

Security

Access Control List (ACL)Yes
IGMP snoopingYes
Security algorithms256-bit AES

Multicast features

Multicast supportYes

Design

Rack mountingYes
StackableYes
Product colourGrey
LED indicatorsYes

Performance

Memory typeDRAM
Internal memory4000 MB
Flash memory8000 MB
FanlessYes

Power

Power sourceAC
Power supply includedYes
AC input voltage115 - 230 V

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes

Weight & dimensions

Width269 mm
Depth244 mm
Height44 mm
Weight3.18 kg

General

Product familyCatalyst
