  • Compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) security requirements
  • Always-on chassis intrusion detection – renders the ATEN PSD PP v4.0 Secure KVM Switch series inoperable when physical tampering is detected
  • Configurable Device Filtration – supports administrative configuration to filter specific USB authentication devices and USB HID devices
  • Port selection via pushbuttons / Remote Port Selector (RPS) only to enhance security

ATEN PSD PP v4.0 Secure KVM Switch CS1148DP4C is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Secure KVM Switch CS1148DP4C is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP).

ATEN PSD PP v4.0 Secure KVM Switch CS1148DP4C provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.

To enhance security, ATEN PSD PP v4.0 Secure KVM Switch CS1148DP4C only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS) 1. With multi–layered security, ATEN PSD PP v4.0 Secure KVM Switch CS1148DP4C ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking and finance institutions, and other organizations that often handle sensitive or confidential data on separate networks.

Ports & interfaces
RJ-11 ports quantity 1
Headphone outputs 8
Audio connections Yes
USB 2.0 Type-A hub ports quantity 1
USB hub Yes
Console DisplayPorts ports quantity 2
Console ports 3.5mm headphone, DisplayPort, USB A
Console USB ports quantity 2
USB 2.0 Type-B ports quantity 16
DisplayPorts quantity 16
Video port type DisplayPort
Mouse port type USB
Keyboard port type USB
Number of computers controlled 8
Performance
Maximum resolution 3840 x 2160 pixels
HD type 4K Ultra HD
Design
Push button Yes
LED indicators Power
Wired remote switch Yes
Housing material Metal
Product colour Black
Display
Built-in display No
Power
Power consumption (typical) 24.4 W
Input current 1.5 A
AC input frequency 50 - 60 Hz
Input voltage 100 - 240 V
Power source AC
Operational conditions
Operating relative humidity (H-H) 0 - 80%
Storage temperature (T-T) -20 - 60 °C
Operating temperature (T-T) 0 - 50 °C
Weight & dimensions
Weight 3.17 kg
Height 65.5 mm
Depth 432.4 mm
Width 204.9 mm
Packaging content
Manual Yes
Cables included AC
