APC
£403.99
Stock Available: 0
  • World class power distribution at an accessible price point.
  • The uncomplicated rPDU that simply provides power for the customer's solutions.
  • Perfect offering for smaller organizations that are without dedicated IT staff.
  • An eco friendly design ensures business contintuity and environmental friendliness.
  • It offers a sustainability the reduces energy waste with a green premium.

The SEP6 Extension for the Basic APC Easy rPDU provides the power for a rack full of devices while being easy to install and inexpensive. It's an integral piece of a plan to deliver a network infrastructure that is standardized and reliable. The SEP6 Extension for the Basic APC Easy rPDU slots perfectly into any data center and supports current solutions with ones to be deployed in the future. It’s nominal power runs between 2.3-22kW and can operate at a maximum temperature of 60C, which is the highest of any Easy rPDU. The SEP6147G is vertical with 11kW, 400V and 16A with 36xC13 and 6xC19 outlets. In addition to the operating high temperature the SEP6 Extension for the Basic APC Easy rPDU has 42 outlets, also more than any other Easy rPDU offering. It's a key part of any enivromental friendly policies and reduces energy waste with a Green Premium. The offerings of Single and Three Phase and the rPDU comes equipped with standardized one single platform with TUV certified safety and EMC report. Thanks to its budget friendly pricepoint, the rPDU is perfect when it comes to current and future AI technologies allowing for business growth and margin improvement. Customer satifaction is guaranteed as the rPDU comes with a standard two year warranty for any field replacement units.

Design
PDU types Basic
Type Three-phase
Rack capacity 0U
Mounting Vertical
Product colour Black
Ports & interfaces
AC outlets quantity 42 AC outlet(s)
Power plug IEC 60309
AC outlet types C13 coupler, C19 coupler
Power
Nominal input voltage 200 - 415 V
AC input frequency 50/60 Hz
Maximum current 16 A
Output voltage 230 V
Maximum power 11000 W
Operational conditions
Operating temperature (T-T) -5 - 60 °C
Storage temperature (T-T) -25 - 60 °C
Operating relative humidity (H-H) 5 - 95%
Weight & dimensions
Width 56 mm
Depth 1500 mm
Height 56 mm
Weight 2.8 kg
Packaging data
Package weight 3.89 kg
Package width 170 mm
Package depth 1660 mm
Package height 126 mm
