SilverNet SIL iSITE Connect
Couldn't load pickup availability
- NXP Industrial Grade Processor
- Global 4G LTE CAT4/3G Network with Dual SIM Cards for backup between multiple Carrier Networks
- Flexible modular design providing Ethernet and Cellular
- Rugged Enclosure with IP30 protection
- Supports 802.11 b/g/n
- Supports SNMP, Modbus Bridging, RIP, OSPF
- 2 x 10/100 BaseT ethernet LAN or 1 x WAN 1 x LAN ports
- Automatic Failover between Ethernet and Cellular
- Supports VPN Tunnels IPsec, iSITE VPN, GRE, L2TP, PPTP, DMVPN
- Supports AAA (Radius, TACACS+, LDAP)
- Embeds hardware watchdog to automatically recover from various failures, ensuring highest level of reliability
- 2 Year Warranty as standard
The SIL iSITE Connect is a cost effective, industrial mobile router with embedded intelligent features that are designed for diverse M2M/IoT applications.
UUtilizing WCDMA, 4G LTE carrier support, and drop-in connectivity, the iSITE range stands out for operators aiming to maximize uptime and reliability.
The iSITE range is highly versatile in various IoT/M2M applications, thanks to its straightforward deployment and comprehensive remote device management through SilverNet's 'iSITE Hub'.
Moreover, by integrating with SilverNet's 'iSITE VPN', secure tunnels to private networks can be established, enhancing security and privacy.
The iSITE Connect uses an embedded cellular modem and contains dual SIM slots for network failover. Thus, the iSITE Connect provides 3G/4G cellular network connectivity with up to 150 Mbps download capacity and up to 50 Mbps uplink.
With 2 fast Ethernet ports and Wi Fi 802.11b/g/n supported, these capabilities can deliver users uninterrupted internet access.
| WAN connection | |
|---|---|
| WAN connection type | RJ-45 |
| 3G/4G USB modem compatibility | No |
| SIM card slot | Yes |
| DSL WAN | No |
| Ethernet WAN | Yes |
| Wireless LAN features | |
|---|---|
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) | 150 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi band | Single-band (2.4 GHz) |
| Network | |
|---|---|
| VPN Passthrough | Yes |
| Static route | Yes |
| Policy-based routing | Yes |
| Dynamic DNS (DDNS) | Yes |
| Automatic channel selection | Yes |
| Load balancing system | Yes |
| Port forwarding | Yes |
| Multicast support | Yes |
| Flow control support | Yes |
| Auto-sensing | Yes |
| Full duplex | Yes |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at |
| Cabling technology | 10/100Base-T(X) |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Mobile network | |
|---|---|
| SIM card type | MicroSIM |
| Dual SIM support | Yes |
| Mobile network generation | 4G |
| Ports & interfaces | |
|---|---|
| RS-232 ports | 1 |
| RS-485 ports | 1 |
| Terminal block port | Yes |
| USB port | No |
| Ethernet LAN (RJ-45) ports | 2 |
| Management features | |
|---|---|
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Bandwidth control | Yes |
| Web-based management | Yes |
| Security | |
|---|---|
| DMZ support | Yes |
| System event log | Yes |
| IP address filtering | Yes |
| MAC address filtering | Yes |
| Filtering | Yes |
| DDoS protection | Yes |
| DoS attack prevention | Yes |
| Access Control List (ACL) | Yes |
| Security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, WPA-AES, WPA-PSK, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP |
| Protocols | |
|---|---|
| Supported network protocols | IPv4/IPv6, PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, ARP, QOS, SNTP, Telnet, VLAN, SSH |
| Management protocols | Web, CLI, SMS, On-demand dial up, SNMP v1/v2/v3 |
| Routing protocols | OSPF, RIP-1, RIP-2, VRRP |
| DHCP server | Yes |
| DHCP client | Yes |
| Design | |
|---|---|
| LED indicators | Activity, LAN, Power, System, VPN, WLAN |
| International Protection (IP) code | IP30 |
| Wall mountable | Yes |
| Housing material | Aluminium |
| Product colour | Black |
| Product type | Portable router |
| Certificates | |
|---|---|
| Certification | CE, FCC, RCMRoHSIEC 61000-4-2 Level 3IEC 61000-4-3 Level 2IEC 61000-4-4 Level 3IEC 61000-4-5 Level 3IEC 61000-4-6 Level 3IEC 61000-4-8 Level 4IEC 61000-4-11 Level 3EN 301 489-1/17/19/52, EN 301 511, EN 301 908-1/2/13, EN 303 413, EN300 328EN62368-1 |
| Packaging content | |
|---|---|
| Antenna included | Yes |
| AC adapter included | Yes |
| Antenna | |
|---|---|
| Antennas quantity | 3 |
| Antenna connector type | RJ-SMA |
| Antenna design | External |
| Features | |
|---|---|
| Electromagnetic compatibility | EN 55032, EN 55035 |
| Firmware upgradeable | Yes |
| Watch Dog function | Yes |
| Flash memory | 128 MB |
| Internal memory | 128 MB |
| Processor frequency | 528 MHz |
| Processor architecture | ARM Cortex A7 |
| Built-in processor | Yes |
| Power | |
|---|---|
| Power consumption (typical) | 1.9 W |
| Power source type | DC |
| Operational conditions | |
|---|---|
| Isolation | 1.5 kV |
| Operating temperature (T-T) | -40 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
|---|---|
| Width | 110 mm |
| Depth | 90 mm |
| Height | 26 mm |
| Weight | 220 g |
| Packaging data | |
|---|---|
| Number of products included | 1 pc(s) |
| Package type | Box |
| Package weight | 580 g |
| Package height | 65 mm |
| Package depth | 215 mm |
| Package width | 115 mm |
| Logistics data | |
|---|---|
| UK Trade Tariff code | 85176200 |
| Country of origin | United Kingdom |
| Warranty period | 2 year(s) |
