Aten
£681.99
Stock Available: 0
  • Extends USB transmission over a Gigabit Ethernet Local Area Network (LAN)
  • ExtremeUSB® – supports transparent USB 2.0 signals and true plug-and-play (no software or drivers required)
  • Pre-paired networked configuration through MAC Address for simple installation. No pairing action required
  • Supports automatic connection link between Local and Remote units through DHCP
  • Up to 100m between extender and switch and between switches over CAT 5e/6/7 cables
  • Operates with all USB peripherals - flash drives, keyboards, mice, webcams, interactive whiteboards, and more
  • Works with all major operating systems: Windows®, OS X®, and Linux®

The UEH4102 4-port USB 2.0 Extender over LAN incorporates patented ExtremeUSB® technology that enables users to extend beyond the standard 5 meter cable limit for USB peripheral devices.

UEH4102 provides true USB 2.0 extension at up to 480 Mbps across a Gigabit Ethernet Local Area Network (LAN). The Local and Remote units are pre-paired with each other through MAC address – no pairing action required during installation.

A true plug-and-play solution, the UEH4102 is compatible with all leading operating systems, and supports all USB peripherals, such as keyboards, mice, interactive white boards, flash drives, hard drives, audio devices, web cameras and any other USB device. The UEH4102 harnesses the full capability of the USB 2.0 standard that provides a durable, reliable and high-quality data communication.

Performance
Linux operating systems supported Yes
Mac operating systems supported Yes
Mac compatibility Yes
Windows operating systems supported Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Cable types supported Cat5e, Cat6, Cat7
Data transfer rate 480 Mbit/s
Maximum transfer distance 100 m
Type Network transmitter & receiver
Ports & interfaces
DC-in jack Yes
USB 2.0 ports quantity 5
RJ-45 ports quantity (receiver) 1
RJ-45 ports quantity (transmitter) 1
Design
LED indicators Yes
Housing material Metal
Product colour Black
Power
Output voltage 5 V
External power adapter Yes
Power consumption (receiver) (max) 15 W
Operational conditions
Storage relative humidity (H-H) 0 - 80%
Operating relative humidity (H-H) 0 - 80%
Storage temperature (T-T) -20 - 70 °C
Operating temperature (T-T) 0 - 50 °C
Weight & dimensions
Weight 190 g
Height 26 mm
Depth 100 mm
Width 76 mm
Packaging content
Manual Yes
Cables included USB
AC adapter included Yes
Logistics data
Harmonized System (HS) code 85176990
