ATEN VS0116 video splitter VGA 16x VGA
£250.99
Couldn't load pickup availability
- One video input to 16 video outputs
- Cascadable to 3 levels - provides up to thousands of video signals
- Audio enabled
- Supports up to 250MHz bandwidth
- Long distance transmission - up to 65 m (210') *
- High video resolution - 1920 x 1440
- DDC, DDC2, DDC2B Compatible (Port 1 only)
- All metal casing
- Designed for enterprise use - 1U in size
- Supports VGA, XGA, SVGA, UXGA and multisync monitors
- OS Support: Windows 2000, Windows XP, Linux, Mac and Sun
- * Video content sent over very long distance using a VGA cable might result in slight degradation of the video signal and quality.
The VS0116 16 Port Video Splitter with Audio duplicates and enhances the video and audio signals from an input source (i.e. a computer) and routes them to up to 16 output devices (monitors, projectors, etc.)Furthermore, it can be cascaded to additional ATEN video splitters to support hundreds of monitors.
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Connector(s) | HDB-15 |
| Audio ports quantity | 1 |
| Video out | 16x VGA |
| Video port type | VGA |
| Video ports quantity | 16 |
| Features | |
|---|---|
| Power LED | Yes |
| HDCP | No |
| Remote control included | No |
| Bandwidth | 250 MHz |
| Maximum operating distance | 65 m |
| 3D | No |
| Maximum resolution | 1920 x 1440 pixels |
| Product colour | Black |
| Network | |
|---|---|
| Ethernet LAN | No |
| Power | |
|---|---|
| USB powered | No |
| Power consumption (typical) | 3.3 W |
| Weight & dimensions | |
|---|---|
| Dimensions (WxDxH) | 433 x 160 x 44 mm |
| Weight | 2.8 kg |
| Packaging content | |
|---|---|
| Manual | Yes |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 50 °C |
