Riello Sentinel Rack 1500 uninterruptible power supply (UPS) Double-conversion (Online) 1.5 kVA 1350 W 1 AC outlet(s)
Couldn't load pickup availability
- Double-conversion (Online)
- 1.5 kVA 1350 W
- Waveform: Sine/Square
- 1 AC outlet(s)
- Sealed Lead Acid (VRLA)
- Rackmount Black
Compactness and total protection for rack systems.
The Sentinel Rack is a rack-mounted version of the popular Sentinel Pro range of ON LINE uninterruptible power supplies. Advanced double conversion technology provides the highest levels of reliability and protection for critical servers, data processing IT systems, and voice/data applications. Available in 1500 VA and 3000 VA versions, both products sit at just 380mm deep, making them the ideal choice to upgrade power in server rooms housing 600 mm deep legacy racks.
For applications requiring several hours of autonomy, the SER 3000 ER is fitted with a 6 A battery charger and additional battery packs for extra runtime. These plug and play UPS systems are designed to fit standard 19" inch cabinet racks and incorporate a Cold Start feature that enables them to power up even if there isn’t a mains supply. Choose from a wide range of operating modes (i.e. ON LINE, ECO, SMART ACTIVE, STANDBY OFF, Frequency Converter) to boost performance and improve energy efficiency.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1.5 kVA |
| Output power | 1350 W |
| Waveform | Sine/Square |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 240 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 180 V |
| Output operation voltage (max) | 264 V |
| Output frequency | 50/60 Hz |
| Output voltage regulation | 5% |
| Surge energy rating | 300 J |
| Response time | 100 ms |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency | 98% |
| Power factor | 0.99 |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Noise level | 40 dB |
| Surge protection | Yes |
| Power protection features | Battery discharge, Over current, Over voltage, Overheating, Short circuit, Under voltage |
| Auto-restart | Yes |
| Power source type | AC |
| Ports & interfaces | |
|---|---|
| AC outlet types | C13 coupler, IEC 320 |
| AC outlets quantity | 1 AC outlet(s) |
| Number of output IEC jumpers | 8 |
| USB port | Yes |
| RS-232 ports | 1 |
| Battery | |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 4 h |
| Design | |
|---|---|
| Form factor | Rackmount |
| Product colour | Black |
| Rack capacity | 1U |
| Cooling type | Active |
| Built-in fan | Yes |
| Control type | Buttons |
| Display type | LED |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Certificates | |
|---|---|
| Compliance certificates | CE, RoHS |
| Certification | CE, L V 2014/35/EU, EMC 2014/30/EU, IEC EN 62040-1; EMC IEC EN 62040-2, IEC 62040-3 VFI - SS - 111 |
| Weight & dimensions | |
|---|---|
| Width | 450 mm |
| Depth | 380 mm |
| Height | 87 mm |
| Weight | 22 kg |
