Lenovo ThinkSystem SR645 server 0 GB Rack (1U) AMD EPYC 7203 2.8 GHz 32 GB DDR4-SDRAM 1100 W
Couldn't load pickup availability
- No OS
- AMD EPYC 7203 (64MB Cache, 2.8GHz)
- 32GB DDR4-SDRAM (1 x 32)
The Lenovo ThinkSystem SR645 is a 2-socket 1U server that features the AMD EPYC 7002 "Rome" and AMD EPYC 7003 "Milan" families of processors. With up to 64 cores per processor and support for the new PCIe 4.0 standard for I/O, the SR645 offers the ultimate in two-socket server performance in a space-saving 1U form factor.
This product guide provides essential pre-sales information to understand the ThinkSystem SR645 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR645 and consider its use in IT solutions.
| Processor | |
|---|---|
| Processor cache | 64 MB |
| Processor cores | 8 |
| Processor frequency | 2.8 GHz |
| Processor model | 7203 |
| Processor family | AMD EPYC |
| Processor manufacturer | AMD |
| Memory | |
|---|---|
| ECC | Yes |
| Memory layout (slots x size) | 1 x 32 GB |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 32 GB |
| Storage | |
|---|---|
| Internal drive bays | 8 |
| Optical drive type | No |
| Supported RAID controllers | 930-8i |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| RAID support | Yes |
| Total storage capacity | 0 GB |
| Graphics | |
|---|---|
| Maximum graphics card memory | 16 MB |
| On-board graphics card model | Matrox G200 |
| On-board graphics card | Yes |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 2.0 ports quantity | 1 |
| Design | |
|---|---|
| Redundant fans support | Yes |
| Product colour | Black, Metallic |
| Chassis type | Rack (1U) |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Noise level | 49 dB |
| Performance management | XClarity Enterprise |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi |
| Operating system installed | No |
| Power | |
|---|---|
| Power supply | 1100 W |
| Redundant power supply (RPS) support | Yes |
| Operational conditions | |
|---|---|
| Operating altitude | 0 - 3050 m |
| Storage relative humidity (H-H) | 8 - 90% |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | 5 - 45 °C |
| General | |
|---|---|
| Product family | ThinkSystem |
| Weight & dimensions | |
|---|---|
| Weight | 20.2 kg |
| Depth | 773 mm |
| Height | 43 mm |
| Width | 440 mm |
