HPE ProLiant MicroServer Gen11 G7400 2c 16GB-U 4LFF-NHP 1TB HDD 180W Ext PS EMEA Cmp Module Server
Couldn't load pickup availability
- Intel® Pentium® Gold G7400 3.7 GHz
- 16 GB 4400 MHz DDR5-SDRAM 1 x 16
- 1 TB
- Ultra Micro Tower 180 W
Are you looking for a budget-friendly server that can fit almost anywhere? The HPE ProLiant MicroServer Gen11 delivers an affordable, compact yet powerful entry server that you can customize for on-premises or for hybrid cloud possibilities while still meeting the enterprise-class performance, security, reliability, and expandability standards of the rest of the HPE ProLiant enterprise class server portfolio. With a mini tower design, place it flat or vertically or wall mounted, depending on customer environment. The latest Intel Xeon 6300 Series, Intel Xeon E and Intel Pentium Processors supported to deliver compute performance, increased memory capacity, as well as security and remote management into the server with HPE iLO silicon root of trust. The affordable starting price makes the HPE ProLiant MicroServer Gen11 a good value that has the networking and performance capacity to grow with your business as your needs and budget change over time.
What is new supporting point:
Fast OS Boot with the M.2 slot (optional slot available on the optional dedicated HPE iLO/M.2/serial port kit).
Optional Serial Port (via the dedicated HPE iLO/M.2/serial port option kit).
Support for HPE iLO 6. HPE iLO remote server management support is now standard without the need of the additional module or activation key.
Four 4400 MT/s HPE DDR5 UDIMMs, offering 16, 32 GB with up to 128 GB memory capacity support.
The latest Intel Xeon 6300 Series, Intel Xeon E-2400 and Intel Pentium Gold Processors.
Two PCIe expansion slots with the new PCIe 5.0 support.
| Processor | |
|---|---|
| Intel® Optane™ Memory Ready | Yes |
| Number of processors installed | 1 |
| Motherboard chipset | Intel C262 |
| Processor cache | 6 MB |
| Processor cores | 2 |
| Performance cores | 2 |
| Performance-core base frequency | 3.7 GHz |
| Processor frequency | 3.7 GHz |
| Processor model | G7400 |
| Processor family | Intel® Pentium® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 128 GB |
| Memory slots | 4x DIMM |
| ECC | Yes |
| Memory clock speed | 4400 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 16 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| Supported RAID controllers | Embedded Intel VROC SATA for HPE ProLiant Gen11 |
| RAID levels | 0, 1, 5, 10 |
| RAID support | Yes |
| SSD interface | SATA III |
| Supported HDD sizes | 3.5" |
| Number of HDDs supported | 4 |
| HDD size | 3.5" |
| HDD interface | SATA III |
| HDD capacity | 1 TB |
| Number of HDDs installed | 1 |
| Total storage capacity | 1 TB |
| Maximum storage capacity | 16 TB |
| Graphics | |
|---|---|
| On-board graphics card model | Intel UHD Graphics 710 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card | Yes |
| Network | |
|---|---|
| LAN controller | Broadcom BCM5719 |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| DisplayPorts quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 4 |
| Expansion slots | |
|---|---|
| PCI Express x16 slots | 1 |
| PCI Express x8 (Gen 4.x) slots | 1 |
| Design | |
|---|---|
| Product colour | Black |
| Chassis type | Ultra Micro Tower |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Power | |
|---|---|
| Power supply input frequency | 50/60 Hz |
| Power supply input voltage | 100 - 240 V |
| Number of main power supplies | 1 |
| Power supply | 180 W |
| Redundant power supply (RPS) support | No |
| Operational conditions | |
|---|---|
| Non-operating altitude | 0 - 9144 m |
| Operating altitude | 0 - 3050 m |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| General | |
|---|---|
| Product family | ProLiant |
| Weight & dimensions | |
|---|---|
| Weight | 7.97 kg |
| Depth | 467 mm |
| Height | 255.4 mm |
| Width | 377 mm |
