HPE ProLiant DL320 Gen11 server 0 GB Rack (2U) Intel® Xeon® Gold 6526Y 2.8 GHz 128 GB DDR5-SDRAM 1000 W
Couldn't load pickup availability
- Intel® Xeon® Gold 6526Y 2.8 GHz
- 128 GB 5600 MHz DDR5-SDRAM 4 x 32
- Rack (2U) 1000 W
Are you looking to run edge AI workloads like Computer Vision that need GPU accelerators or distributed data solutions that require expandable storage? The HPE ProLiant DL320 Gen11 is a 1U 1P server with a unique compact design and workload-driven modular design that is purpose-built for edge computing delivering exceptional performance at 1P economics and an excellent choice for both virtualized and containerized workloads. Powered by 4th and 5th Gen Intel Xeon Scalable Processors with up to 60 cores, 270W, increased memory capability (up to 2 TB 5600 MT/s), and high-speed PCIe Gen5 supporting up to four single-wide GPUs (or two double-wide), the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution. The HPE ProLiant Gen11 servers are engineered to optimize IT at the edge with a cloud operating experience, built-in security, and optimized performance for workloads to drive your business forward.
What is new supporting point:
Powered by the 4th and 5th Gen Intel Xeon Scalable Processors with next-generation 5nm technology that supports up to 60 cores at 270W and 16 DIMMs of DDR5 memory up to 5600 MT/s.
16 DIMMs per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP3.0 slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
Supports hot-pluggable or internal, high-availability RAID1 NVMe M.2 boot options.
Support for up to 4 Single Wide or 2 Double Wide GPUs in the front cage with the GPU CTO server.
| Processor | |
|---|---|
| Number of processors installed | 1 |
| Processor cache | 37.5 MB |
| Processor cores | 16 |
| Performance cores | 16 |
| Processor boost frequency | 3.9 GHz |
| Processor frequency | 2.8 GHz |
| Processor model | 6526Y |
| Processor family | Intel® Xeon® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 2.05 TB |
| ECC | Yes |
| Memory clock speed | 5600 MHz |
| Memory layout (slots x size) | 4 x 32 GB |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 128 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| Hot-Plug support | Yes |
| Supported RAID controllers | HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device |
| RAID levels | 0, 1, 5, 10 |
| RAID support | Yes |
| Number of SSDs supported | 4 |
| Supported SSD sizes | 3.5" |
| SSD interface | PCI Express 4.0 |
| Supported HDD sizes | 3.5" |
| Number of HDDs supported | 4 |
| HDD interface | SATA |
| Total storage capacity | 0 GB |
| Maximum storage capacity | 24 TB |
| Graphics | |
|---|---|
| Maximum graphics card memory | 16 MB |
| On-board graphics card | Yes |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 2 |
| Design | |
|---|---|
| Rack mounting | Yes |
| Chassis type | Rack (2U) |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Remote administration | iLO 6 ASIC |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows ServerVMware ESXiRed Hat Enterprise Linux (RHEL)SUSE Linux Enterprise Server (SLES)Canonical UbuntuOracle Linux and Oracle VMCitrixCommunity Enterprise Linux (CentOS, Alma Linux, Rocky Linux) |
| Operating system installed | No |
| Power | |
|---|---|
| Number of main power supplies | 2 |
| Number of redundant power supplies installed | 2 |
| Power supply | 1000 W |
| Redundant power supply (RPS) support | Yes |
| Operational conditions | |
|---|---|
| Non-operating altitude | 0 - 9144 m |
| Operating altitude | 0 - 3050 m |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| General | |
|---|---|
| Product family | ProLiant |
| Product series | DL |
| Sustainability | |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
|---|---|
| Depth | 664.7 mm |
| Height | 42.8 mm |
| Width | 434.6 mm |
