Axis Q3839-SPVE Dome IP security camera Outdoor 7552 x 3776 pixels Wall
Couldn't load pickup availability
- Withstand corrosive and harsh conditions
- 8K multisensor camera with one IP address
- AI-powered with support for advanced analytics
- Horizon straightening and lossless zoom
- Built-in cybersecurity with Axis Edge Vault
Enclosed in a marine-grade stainless steel casing, this AI-powered, multisensor camera is made for the toughest conditions. It delivers ultra-high 180° panoramic overviews with no blind spots for complete situational awareness.
Robust and secure in corrosive areas
AXIS Q3839-SPVE comes in a stainless steel (EN1.440 SS 316L) casing and can withstand the corrosive effects of seawater, making it ideal for wide area surveillance in marine environments such as on ships and in harbors. Plus, it can operate in temperatures from -50 °C to 55 °C (-58 ºF to 131 ºF). Easy to clean and maintain, and resistant to cleaning chemicals, it’s also certified by NSF/ANSI to Standard 169 (Special Purpose Food Equipment and Devices) for use in food processing facilities. What’s more, this robust camera comes with Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and offers FIPS 140-2 Level 2 certified key storage and operations.
Ultra clear overview with no blind spots
Get the benefits of four cameras while paying for just one with this cost-effective device. It ensures fast, cost-efficient installation, and there’s a variety of mounting options available. It offers 180° horizontal coverage and 90° vertical coverage with no blind spots. And with up to 8K horizontal resolution at 30 fps and seamless stitching of all four images, you’ll enjoy smooth and cohesive 180° panoramic overviews. Thanks to lossless zoom, it’s possible to zoom in without degrading image sharpness. Edge-to-edge technology lets you easily add whatever connectivity devices you need. Furthermore, horizon straightening ensures visually balanced images.
AI-powered for valuable insights
Built on a dual Axis system-on-chip, this AI-powered camera includes a deep learning processing unit (DLPU) so you can run powerful features and analytics on the edge. For instance, AXIS Object Analytics can detect, classify, track, and count humans and types of vehicles. This DLPU also ensures improved processing and storage capabilities. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Furthermore, when AXIS Q3839-SPVE is paired with an Axis radar device, you can take advantage of AXIS Radar Data Visualizer, a powerful application that adds value to and increases the functionality of Axis multisensor cameras.
| Performance | |
|---|---|
| Certification | UL/cUL, BIS, CE, KC, VCCI, RCM |
| Languages support | Multi |
| Built-in heater | Yes |
| Dynamic range | 120 dB |
| Infrared (IR) cut-off filter | Yes |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| PTZ control | Yes |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Type | IP security camera |
| Design | |
|---|---|
| IK code | IK10 |
| International Protection (IP) code | IP66, IP67, IP68, IP69K |
| Protection features | Water resistant |
| Housing material | Plastic |
| Product colour | Black |
| Mounting type | Wall |
| Form factor | Dome |
| Camera | |
|---|---|
| Camera shutter speed | 1/8500 - 1/5 s |
| Pan range | -176 - 176° |
| Tilt angle range | 30 - 88° |
| Lens viewing angle, vertical | 90° |
| Lens viewing angle, horizontal | 180° |
| Minimum illumination | 0.03 lx |
| Image sensor | |
|---|---|
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 4 |
| Sensor type | CMOS |
| Lens system | |
|---|---|
| Fixed focal length | 4.6 mm |
| Identify distance | 8.8 m |
| Maximum aperture number | 1.8 |
| Recognize distance | 17.7 m |
| Observe distance | 35 m |
| Detect distance | 88.3 m |
| Zoom capability | Yes |
| Night vision | |
|---|---|
| Night vision | Yes |
| Video | |
|---|---|
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness, White balance |
| Privacy masking | Yes |
| Automatic gain control | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Noise reduction | Yes |
| Video streaming | Yes |
| Frame rate | 30 fps |
| Video compression formats | H.264, H.265 |
| Total megapixels | 8.3 MP |
| Maximum resolution | 7552 x 3776 pixels |
| Audio | |
|---|---|
| Sample rates | 8 - 48 kHz |
| Built-in microphone | Yes |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Audio formats supported | AAC-LC, ADPCM, G.711, G.726, LPCM, PCM |
| Audio system | 1-way |
| Built-in speaker(s) | Yes |
| Network | |
|---|---|
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS2, HTTP/ 2, TLS2, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB- II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf), IEEE 802.1X (EAP-TLS), IEEE 802.1AR |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Storage | |
|---|---|
| Internal memory | 4000 MB |
| Flash memory | 8000 MB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Ports & interfaces | |
|---|---|
| Terminal block port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
|---|---|
| Human and vehicle targets classification | Yes |
| Intelligent Video Surveillance (IVS) system features | Crossing line, Line crossing detection |
| Security algorithms | 802.1x RADIUS, EAP-TLS, MSCHAPv2, PEAP |
| Privacy protection | Yes |
| Network access storage (NAS) | Yes |
| Power | |
|---|---|
| Power consumption (max) | 19.1 W |
| Power consumption (typical) | 9.74 W |
| Power source type | DC, PoE |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating temperature (T-T) | -40 - 50 °C |
| Weight & dimensions | |
|---|---|
| Weight | 4.8 kg |
| Diameter | 25.6 cm |
| Height | 195.2 mm |
| Packaging data | |
|---|---|
| Package type | Box |
| Packaging content | |
|---|---|
| User guide | Yes |
| Wall mounting kit | Yes |
| Terminal block included | Yes |
| Number of cameras | 1 |
| Technical details | |
|---|---|
| Iris | Yes |
| Other features | |
|---|---|
| I/O ports | Audio in/out |
