Axis M4227-LVE Dome IP security camera Outdoor 2688 x 1512 pixels Wall
Couldn't load pickup availability
- Outdoor IP security camera
- CMOS 25.4 / 2.7 mm (1 / 2.7") 5 MP 2688 x 1512 pixels
- Wired Ethernet LAN
- Night vision 20 m IR
- Dome Wall
- IP66 IK10 Weatherproof
- Black, White
- 540 g
AXIS M4227-LVE Dome Camera
This compact, varifocal dome camera offers great images in 5 MP. It comes preinstalled with AXIS Object Analytics, as well as AXIS Audio Analytics to detect and classify specific sounds as well as sudden changes in sound volume.
Great images, every time
AXIS M4227-LVE delivers great image quality in 5 MP. Featuring a varifocal lens with 98°-38° field of view and remote zoom and focus capabilities, it can be adapted for close-ups and overviews without the need for hands-on fine tuning. Thanks to Lightfinder 2.0 and Forensic WDR, it provides details even in challenging light conditions. Plus, OptimizedIR allows for surveillance in total darkness without the need for extra lighting. Furthermore, Axis Zipstream with support for H.264 and H.265 significantly reduces bandwidth and storage requirements without compromising image quality.
Powerful with strong security
Featuring a deep learning processing unit (DLPU), AXIS M4227-LVE lets you run advanced features and powerful analytics on the edge. For instance, it comes preinstalled with AXIS Object Analytics to detect, classify, track, and count objects such as humans and vehicles. It includes an acoustic sensor, so it’s out-of-the-box-ready for AXIS Audio Analytics which can detect and classify specific sounds as well as sudden changes in sound volume. In addition, Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified, secure cryptographic key storage and operations.
Small and discreet
This compact and discreet dome camera blends in with any environment. There’s also a smoked dome available as an accessory, so you can disguise which way the camera is pointing. This IP66- and IK10-rated camera has an operating temperature range from -30°C to 50°C (-22°F to 122°F). Plus, the included weathershield offers extra protection.
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Preset points | Yes |
| Tour recording | Yes |
| Auto-tracking | Yes |
| PTZ modes | Digital PTZ |
| PTZ control | Yes |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Type | IP security camera |
| Design | |
|---|---|
| Weatherproof | Yes |
| IK code | IK10 |
| International Protection (IP) code | IP66 |
| Housing material | Plastic, Polycarbonate (PC) |
| LED indicators | Yes |
| Product colour | Black, White |
| Mounting type | Wall |
| Form factor | Dome |
| Camera | |
|---|---|
| Camera shutter speed | 1/33500 - 1.5 s |
| Camera pixel size | 2.92 µm |
| Pan range | -180 - 180° |
| Tilt angle range | -10 - 65° |
| Lens viewing angle, vertical | 66° |
| Lens viewing angle, horizontal | 98° |
| Angle of rotation | 360° |
| Minimum illumination | 0.03 lx |
| Camera tilt control | Yes |
| Camera pan control | Yes |
| Image sensor | |
|---|---|
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Number of sensors | 1 |
| Sensor type | CMOS |
| Panoramic camera | |
|---|---|
| Signal-to-Noise Ratio (SNR) (panoramic camera) | 55 dB |
| Lens system | |
|---|---|
| Closest focusing distance | 1 m |
| Identify distance (tele) | 20.4 m |
| Detect distance (wide) | 87.5 m |
| Detect distance (tele) | 203.6 m |
| Observe distance (wide) | 34.7 m |
| Observe distance (tele) | 80.8 m |
| Recognize distance (wide) | 17.5 m |
| Recognize distance (tele) | 40.7 m |
| Identify distance (wide) | 8.8 m |
| Maximum aperture number | 2.7 |
| Minimum aperture number | 2.9 |
| Auto focus | Yes |
| Focal length range | 3.2 - 7.2 mm |
| Zoom capability | Yes |
| Number of lenses | 1 |
| Night vision | |
|---|---|
| Infra-red wavelength | 850 nm |
| LED type | IR |
| Night vision distance | 20 m |
| Night vision | Yes |
| Video | |
|---|---|
| Flip & mirror | Yes |
| Text caption overlay | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Bit rate control | Variable Bit Rate (VBR) |
| Video streaming | Yes |
| Frame rate | 30 fps |
| Supported graphics resolutions | 320 x 240, 640 x 360, 2592 x 1944, 2688 x 1512 |
| Video formats supported | AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Total megapixels | 5 MP |
| Maximum resolution | 2688 x 1512 pixels |
| Audio | |
|---|---|
| Audio detection | Yes |
| Network | |
|---|---|
| Streaming method | Multicast |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Networking standards | IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Storage | |
|---|---|
| RAM capacity | 2000 MB |
| Flash memory | 8000 MB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Security | |
|---|---|
| Human and vehicle targets classification | Yes |
| Intelligent Video Surveillance (IVS) system features | Abandoned object, Line crossing detection, Moving object |
| Security algorithms | EAP-TLS, HTTPS, MSCHAPv2, PEAP, TLS |
| Privacy protection | Yes |
| Management features | |
|---|---|
| Cloud-managed | Yes |
| Power | |
|---|---|
| Power consumption (max) | 12.3 W |
| Power consumption (typical) | 3.1 W |
| Power source type | PoE |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating temperature (T-T) | -30 - 50 °C |
| Weight & dimensions | |
|---|---|
| Weight | 540 g |
| Height | 126 mm |
| Depth | 112 mm |
| Width | 140 mm |
| Sustainability | |
|---|---|
| Compliance certificates | BSMI, CE, EAC, RCM, REACH, RoHS, Trade Agreements Act (TAA), UKCA, UL, VCCI, cUL |
| Packaging content | |
|---|---|
| Manual | Yes |
| Sun shield included | Yes |
| Number of cameras | 1 |
| Other features | |
|---|---|
| Doesn't contain | Brominated Flame Retardant (BFR), CFR, PVC |
