HPE Xeon Intel -Gold 6338 2.0GHz 32-core 205W Processor Kit for ProLiant XL2x0n Gen10 Plus
£5,063.99
Couldn't load pickup availability
- Intel® Xeon® Gold 6338 2 GHz
- 48 MB L3 LGA 4189
- Processor cores: 32 10 nm 64-bit 205 W
- Maximum internal memory supported by processor: 6 TB DDR4-SDRAM
.
| Processor | |
|---|---|
| Processor codename | Ice Lake |
| Bus type | UPI |
| Thermal Design Power (TDP) | 205 W |
| Processor cache type | L3 |
| Processor cache | 48 MB |
| Low priority core frequency | 1.8 GHz |
| Low priority cores | 20 |
| High priority core frequency | 2.2 GHz |
| High priority cores | 12 |
| Processor boost frequency | 3.2 GHz |
| Processor operating modes | 64-bit |
| System bus rate | 11.2 GT/s |
| Processor threads | 64 |
| Processor series | Intel Xeon Gold 6000 Series |
| Processor lithography | 10 nm |
| Processor socket | LGA 4189 |
| Processor cores | 32 |
| Processor base frequency | 2 GHz |
| Processor model | 6338 |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor family | Intel® Xeon® Gold |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Octa-channel |
| Memory clock speeds supported by processor | 3200 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Maximum internal memory supported by processor | 6 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Scalability | 2S |
| Embedded options available | No |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| PCI Express slots version | 4.0 |
| Maximum number of PCI Express lanes | 64 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel® Speed Select Technology – Turbo Frequency | Yes |
| Intel® Speed Select Technology – Core Power | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Maximum Enclave Size Support for Intel® SGX | 64 GB |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| General | |
|---|---|
| Product family | Xeon |
| Weight & dimensions | |
|---|---|
| Height | 169.7 mm |
| Depth | 285.7 mm |
| Width | 174.8 mm |
