HPE Intel Xeon-Platinum 8360Y 2.4GHz 36-core 250W Processor for
£10,832.99
Couldn't load pickup availability
- Intel® Xeon® Platinum 8360Y 2.4 GHz
- 54 MB L3 LGA 4189
- Processor cores: 36 10 nm 64-bit 250 W
- Maximum internal memory supported by processor: 6.14 TB DDR4-SDRAM
- Tray
.
| Processor | |
|---|---|
| Processor ARK ID | 212459 |
| Processor codename | Ice Lake |
| Thermal Design Power (TDP) | 250 W |
| Processor cache type | L3 |
| Processor cache | 54 MB |
| Low priority core frequency | 2.1 GHz |
| Low priority cores | 24 |
| High priority core frequency | 2.7 GHz |
| High priority cores | 12 |
| Processor boost frequency | 3.5 GHz |
| Processor operating modes | 64-bit |
| System bus rate | 11.2 GT/s |
| Processor threads | 72 |
| Component for | Server/workstation |
| Cooler included | No |
| Processor lithography | 10 nm |
| Processor socket | LGA 4189 |
| Processor cores | 36 |
| Processor base frequency | 2.4 GHz |
| Processor model | 8360Y |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor family | Intel® Xeon® Platinum |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Octa-channel |
| Memory clock speeds supported by processor | 3200 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Maximum internal memory supported by processor | 6.14 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | G178966 |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Scalability | 2S |
| Embedded options available | No |
| Supported instruction sets | SSE4.2, AVX, AVX 2.0, AVX-512 |
| PCI Express slots version | 4.0 |
| Maximum number of PCI Express lanes | 64 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Maximum Enclave Size Support for Intel® SGX | 64 GB |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Operational conditions | |
|---|---|
| Tcase | 80 °C |
| Packaging data | |
|---|---|
| Package type | Tray |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85423119 |
| Technical details | |
|---|---|
| Servicing status | Baseline Servicing |
| Launch date | Q2'21 |
| Status | Launched |
| Memory speed (max) | 3200 MHz |
| Number of UPI links | 3 |
| Target market | High Performance Computing |
| Supported memory types | DDR4-SDRAM |
| Weight & dimensions | |
|---|---|
| Processor package size | 77.5 x 56.5 mm |
| Height | 292.1 mm |
| Other features | |
|---|---|
| Maximum internal memory | 6 TB |
