£1,753.99

Stock Available: 0
  • Remotely reboot outlets to power cycle unresponsive IT equipment or increase runtime of critical equipment upon power failure with outlet-level control
  • Reliable power distribution with local and remote outlet-level power monitoring options offer quick access to critical power usage information down to the device level to evaluate energy usage trends and maximize uptime
  • Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime
  • Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a break in the network chain occurs. Supports up to 40 rPDUs
  • Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices

Rack Transfer Switch (RTS) delivers redundant power to single corded devices. The RTS automatically detects the loss of power and switches the power load (no phase-syncronization required) to the alternative power source in less than 4-8 milliseconds without the need for human intervention.

Design
Display LED
Product colour Black
Mounting Horizontal
Rack capacity 0U
Type Single-phase
PDU types Monitored, Switched
Ports & interfaces
USB ports quantity 1
Ethernet LAN (RJ-45) ports 1
Serial ports quantity 1
AC outlet types C13 coupler, C19 coupler
Power plug IEC 60309
AC outlets quantity 6 AC outlet(s)
Features
Cable length 3 m
Reset button Yes
Management features
Supported network protocols DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP
Monitoring Current, Power, Voltage
Power
Load capacity 230 VA
Maximum current 16 A
AC input frequency 50/60 Hz
Nominal input voltage 200-240 V
Operational conditions
Operating temperature (T-T) 0 - 60 °C
Weight & dimensions
Height 44 mm
Depth 457 mm
Width 432 mm
Packaging data
Package weight 5.44 kg
General
Product family Geist
