Shuttle XPC cube Barebone SH570R8 - S1200, Intel H570, 1x PCIe X16, 1x PCIe X4, 2x LAN,1x HDMI, 2x DP, 4x 3.5" HDD bays
£147.99
Couldn't load pickup availability
- 13L sized PC Black
- Intel
- 4 DIMM Maximum internal memory: 128 GB DDR4-SDRAM
- HDD & SSD 2.5,3.5,M.2
- On-board graphics card Intel® UHD Graphics
- Ethernet LAN Wi-Fi
The Shuttle XPC cube Barebone SH570R8 is able to accommodate up to four 3.5 inch hard drives for enormous storage capacity - ideal for both home and commercial applications. However, this barebones platform is way more than just about storage - the SH570R8 has enough grunt under its aluminium bonnet to be a high-end gaming PC or a workstation for intensive graphics or even video applications. Its black-brushed aluminium case shows how discreet and stylish a powerful PC can look.
| Processor | |
|---|---|
| Built-in processor | No |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Memory voltage | 1.2 V |
| Memory channels | Dual-channel |
| Maximum internal memory | 128 GB |
| Supported memory clock speeds | 2666,2933,3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Storage | |
|---|---|
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express, Serial ATA III |
| Graphics | |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel® UHD Graphics |
| Audio | |
|---|---|
| Built-in speaker(s) | No |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Bluetooth version | 4.2 |
| Bluetooth | Yes |
| Ports & interfaces | |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Design | |
|---|---|
| Chassis type | 13L sized PC |
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Yes |
| Housing material | Aluminium |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product type | PC barebone |
| Performance | |
|---|---|
| Motherboard form factor | ATX |
| Processor socket | LGA 1200 (Socket H5) |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel Pentium G |
| BIOS type | AMI |
| BIOS memory size | 16 Mbit |
| Audio chip | Realtek ALC897 |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84713000 |
| Software | |
|---|---|
| Windows operating systems supported | Windows 10 |
| Linux operating systems supported | Yes |
| Operating system installed | No |
| Power | |
|---|---|
| Power supply type | Internal power supply unit |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Number of power supply units | 1 |
| Power supply | 500 W |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Width | 215 mm |
| Depth | 332 mm |
| Height | 190 mm |
| Weight | 3.5 kg |
| Package weight | 4.5 kg |
| Packaging content | |
|---|---|
| Power cord included | Yes |
| Quick start guide | Yes |
| Other features | |
|---|---|
| Country of origin | China |
