Intel BOXNUC7I7BNH PC/workstation barebone Black i7-7567U 3.5 GHz
£518.99
Couldn't load pickup availability
- Black
- Built-in processor Intel i7-7567U 3.5 GHz
- 2 SO-DIMM Maximum internal memory: 32 GB DDR4-SDRAM
- HDD & SSD M.2,2.5
- On-board graphics card Intel® Iris™ Plus Graphics 650
- Ethernet LAN Wi-Fi
Get ready to play hard and fast while still taking advantage of the performance you need for content creation, photo editing, or complex work. The Intel® NUC Kit NUC7i7BNH is built with a dual-core 7th Generation Intel® Core™ i7 processor and has Intel® Turbo Boost Technology 2.0 for unprecedented power and responsiveness. With dual-array front microphones you can take full advantage of Windows® 10 and Cortana. Now you’ve got your own digital personal assistant to keep you on time to meetings, help you send email, or find that stat you need for your boss. Intel® Iris™ Plus graphics gives users true visual perfection in 4K Ultra HD and the system can support up to three 4K displays. Plus, you’ll wield the power to create, edit, and share 4K content—all with the lightning speed data transfers of Thunderbolt™ 3 technology. Also includes a 2.5" drive bay for an SSD or HDD with up to 2 TB of storage.
| Processor | |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor generation | 7th gen Intel® Core™ i7 |
| Processor model | i7-7567U |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor boost frequency | 4 GHz |
| Processor frequency | 3.5 GHz |
| Processor lithography | 14 nm |
| Processor cache | 4 MB |
| L3 cache | 4 MB |
| Thermal Design Power (TDP) | 28 W |
| Memory bandwidth supported by processor (max) | 34.1 GB/s |
| Processor codename | Kaby Lake |
| CPU configuration (max) | 1 |
| Memory | |
|---|---|
| Memory slots type | SO-DIMM |
| Number of DIMM slots | 2 |
| Number of memory slots | 2 |
| Removable memory card slot | microSDXC with UHS-I support |
| Memory bandwidth (max) | 34.1 GB/s |
| Memory voltage | 1.2 V |
| Memory channels | Dual-channel |
| Maximum internal memory | 32 GB |
| Supported memory clock speeds | 2133 MHz |
| Supported memory types | DDR4-SDRAM |
| ECC | No |
| Storage | |
|---|---|
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | M.2,2.5 |
| SSD form factor | M.2 |
| Storage drive interface | M.2, PCI Express, Serial ATA III |
| Number of storage drives supported | 2 |
| Maximum storage capacity | 2 TB |
| RAID levels | 0, 1 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSDXC |
| Graphics | |
|---|---|
| On-board graphics card | Yes |
| Graphics card family | Intel |
| On-board graphics card model | Intel® Iris™ Plus Graphics 650 |
| Maximum graphics card memory | 32000 MB |
| Number of displays supported | 3 |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| WLAN controller model | Intel Dual Band Wireless-AC 8265 |
| LAN controller | Intel® I219-V |
| Bluetooth version | 4.2 |
| Bluetooth | Yes |
| Ports & interfaces | |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0a |
| Combo headphone/mic port | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| M.2 card slot (storage) | 2242/2280 |
| USB ports quantity | 6 |
| Number of SATA III connectors | 2 |
| Thunderbolt 3 ports quantity | 1 |
| Thunderbolt ports quantity | 1 |
| Graphics output | HDMI 2.0a; USB-C (DP1.2) |
| Expansion slots | |
|---|---|
| PCI Express slots version | 3.0 |
| PCI Express x4 slots | 1 |
| PCI Express configurations | 1x2, 1x4, 2x2, 2x1, 4x1 |
| Design | |
|---|---|
| Product colour | Black |
| Cooling type | Passive |
| On/off switch | Yes |
| LED indicators | Power |
| VESA mounting | Yes |
| Product type | Mini PC barebone |
| ARK ID | 95065 |
| Status | Discontinued |
| Product series | Intel® NUC Kit with 7th Generation Intel® Core™ Processors |
| Product codename | Baby Canyon |
| Performance | |
|---|---|
| Motherboard form factor | UCFF |
| BIOS type | EEPROM |
| BIOS memory size | 64 Mbit |
| Trusted Platform Module (TPM) | No |
| Audio output channels | 7.1 channels |
| Consumer infrared Rx sensor | Yes |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Export Control Classification Number (ECCN) | 5A992C |
| Supported RAID configuration | 2.5" HDD/SSD + M.2 SATA SSD (RAID-0 RAID-1) |
| Processor special features | |
|---|---|
| Intel® vPro™ Platform Eligibility | No |
| Intel Express BIOS update | Yes |
| Intel Visual BIOS | Yes |
| Intel® Smart Cache | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Smart Response Technology | Yes |
| Intel Clear Video Technology | Yes |
| Intel® OS Guard | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel® Secure Key | Yes |
| Intel TSX-NI | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Idle States | Yes |
| Intel 64 | Yes |
| Intel Rapid Storage Technology | Yes |
| Intel® Platform Trust Technology (Intel® PTT) | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Execute Disable Bit | Yes |
| Intel Trusted Execution Technology | No |
| Intel Flex Memory Access | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Embedded options available | No |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84713000 |
| Software | |
|---|---|
| Compatible operating systems | Windows 10, 64-bit* |
| Operating system installed | No |
| Certificates | |
|---|---|
| Certification | ROHS, WEEE |
| Power | |
|---|---|
| Power supply type | External AC adapter |
| AC adapter output voltage | 19 V |
| Power supply | 65 W |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Width | 115 mm |
| Depth | 111 mm |
| Height | 51 mm |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
| Processor included | Intel® Core™ i7-7567U Processor (4M Cache, up to 4.00 GHz) |
| Other features | |
|---|---|
| Additional headers | CEC, 2x USB2.0, FRONT_PANEL |
| HDD size | 2.5" |
| Processor ARK ID | 97541 |
| Number of SATA connectors | 2 |
| DC input voltage | 12 - 19 V |
| Launch date | Q1'17 |
