SilverNet
£945.99
Stock Available: 0
  • 24 x 10/100/1000M Base TX RJ45 Ports
  • 4 xGigabit Combo (SFP/RJ45) Ports
  • Auto Negotiation
  • Full/Half Duplex
  • Auto MDI/MDI X Connection-
  • 4Mbits Packet Buffer Size-
  • 8K MAC Address Table-
  • 10K Jumbo Packets
  • IEEE 802.3af/at PoE+
  • Advanced PoE Functions: Output Setting, Smart PoE, PoE Scheduling and Budget Management
  • Web GUI / CLI / NMS Management
  • Redundant Network with STP/RSTP/ERPSv2
  • RADIUS, IEEE 802.1X, SNMPv3, HTTPs, SSH
  • 5 Year Warranty

The SIL 734C24MP is a top-tier Industrial Managed Ethernet Switch for industrial Ethernet networks. Developed and built to industry-leading technical standards, it ensures stable and reliable Ethernet transmission with superior quality you can depend on.

Housed in rack-mountable, strong aluminium casing, this Switch boasts a total of 24 Ethernet ports. On top of that, it also has 4 additional Gigabit SFP ports for data uplink and backbone connectivity.

Perfectly equipped to meet infrastructure requirements of a high-density PoE/PoE+ supply it is able to supply power to PD terminal equipment, like wireless APs, webcams, VoIP devices, and visual intelligent building intercoms through network cable.

The advanced technology and open network standards employed by this Switch allow it to function efficiently in all sorts of demanding environments. It can withstand extreme temperature ranges, resist electromagnetic interference, salt fog, vibrations, and shaking.

This Switch is specifically designed for challenging environments, e.g. industrial networking and intelligent transportation systems (ITS), and feature standard IP40 protection. Even where environmental conditions exceed commercial product specifications, like in military and utility sectors, this Switch can be relied upon for long-lasting high-performance.

Management features
System event log Yes
Traffic classification Yes
Traffic shaping Yes
ARP inspection Yes
Web-based management Yes
Quality of Service (QoS) support Yes
Switch layer L2+
Switch type Managed
Ports & interfaces
Power connector Terminal block (6-pin)
SFP module slots quantity 4
Combo SFP ports quantity 4
Gigabit Ethernet (copper) ports quantity 24
Fast Ethernet (copper) ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 24
Network
Number of VLANs 256
Virtual LAN features Multiple VXLAN (MUX VLAN), Port-based VLAN, Tagged VLAN
VLAN support Yes
Link aggregation Yes
Flow control support Yes
Auto MDI/MDI-X Yes
Auto-negotiation Yes
Rate limiting Yes
Broadcast storm control Yes
Spanning tree protocol Yes
Half duplex Yes
IP routing Yes
Full duplex Yes
Port mirroring Yes
Copper ethernet cabling technology 10BASE-TX, 100BASE-TX, 1000BASE-TX
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Optical fiber
Fiber ethernet cabling technology 1000Base-X
Data transmission
Packet buffer memory 4 MB
Jumbo frames 10000
Jumbo frames support Yes
Static route Yes
Latency (1 Gbps) 7 µs
Latency (10-100 Mbps) 7 µs
Switching capacity 56 Gbit/s
MAC address table 8000 entries
Security
Loop protection Yes
Security algorithms 802.1x RADIUS, HTTPS, SNMPv3, SSH-2, SSL/TLS
Authentication MAC-based authentication, Port-based authentication
Authentication type IEEE 802.1x, RADIUS
Queue scheduling algorithms SP, WRR+SP, Weighted Round Robin (WRR)
MAC address entries Blackhole MAC address entries, Static MAC address entries
MAC address filtering Yes
Password protection Yes
SSH/SSL support Yes
IP-MAC-Port binding Yes
Static port security Yes
IGMP snooping Yes
Access Control List (ACL) Yes
DHCP features DHCP client, DHCP server, DHCPv6 client, DHCPv6 server
Multicast features
Multicast support Yes
Design
Electromagnetic compatibility EN55032 Class A, CISPR 32 FCC Part 15B Class A, EN61000 4 2 (ESD) EN61000 4 3 (RS) EN61000 4 4 (EFT) EN61000 4 5 (Surge) EN61000 4 6 (CS) EN61000 4 8 (PFMF)
International Protection (IP) code IP40
LED indicators Alarm, LAN, Link, Power, Ring
Housing material Aluminium
Product colour Black
Form factor 19U
Stackable Yes
Rack mounting Yes
Performance
Mean time between failures (MTBF) 250000 h
Fanless Yes
Firmware upgradeable Yes
Noise level 0 dB
Power
Power protection features Overload, Reverse polarity
Power consumption (max) 24 W
DC input voltage 9 - 56 V
Number of power supply units 2
Redundant power supply (RPS) support Yes
Power source DC
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 720 W
Power over Ethernet (PoE) power per port 30 W
Power over Ethernet (PoE) voltage 48 V
Power over Ethernet (PoE) ports quantity 24
Power over Ethernet (PoE) type supported Active PoE
Power over Ethernet (PoE) Yes
Other features
Warranty period 5 year(s)
Operational conditions
Operating relative humidity (H-H) 5 - 90%
Storage temperature (T-T) -40 - 85 °C
Operating temperature (T-T) -40 - 75 °C
Weight & dimensions
Weight 2.6 kg
Height 45 mm
Depth 300 mm
Width 400 mm
Packaging content
Rack mount kit Yes
Packaging data
Package weight 3.24 kg
Package height 80 mm
Package depth 495 mm
Package width 393 mm
Package type Box
Certificates
Certification IEC/EN 62368-1IEC 60068-2-27IEC 60068-2-32IEC 60068-2-6RoHS
Logistics data
UK Trade Tariff code 85176200
