Allied Telesis AT-DMC100/LC-90 network media converter 100 Mbit/s 1310 nm Multi-mode Grey
£157.99
Couldn't load pickup availability
- Wired
- 100 Mbit/s 2000 m 1310 nm
- 100BASE-FX
- Ethernet LAN (RJ-45) ports: 1
- Multi-mode Fiber ports quantity: 1 LC 50/125,62.5/125 µm
- DIN rail mounting
- Grey
Overview
At just 1.25 inches wide × 3.6 inches deep × 0.85 inches high, Allied Telesis DMC Series media converters can easily fit into the palm of a hand. In addition to being compact—with a small carbon footprint—the DMC Series can also be powered with the included Micro USB to USB cable, and plugged directly into a laptop or PC or may also be powered via the optional AC/DC adapter. This saves installation time and cabling as there are no further power requirements
| Network | |
|---|---|
| Link Loss Return (LLR) supported | Yes |
| Link Loss Carry Forward (LLCF) supported | Yes |
| Duplex system | Full, Half |
| Auto-negotiation | Yes |
| Auto MDI/MDI-X | Yes |
| Data transfer rate | 100 Mbit/s |
| Fiber ethernet cabling technology | 100BASE-FX |
| Networking standards | IEEE 802.1Q |
| Converter output interface | 100Base-FX |
| Converter input interface | 100Base-TX |
| Maximum data transfer rate | 100 Mbit/s |
| Performance | |
|---|---|
| Rx power (max) | -14 dBmW |
| Rx power (min) | -32 dBmW |
| Tx power (max) | -14 dBmW |
| Tx power (min) | -22.5 dBmW |
| Fiber cable diameters supported (core/cladding) | 50/125,62.5/125 µm |
| Fiber mode structure | Multi-mode |
| Wavelength | 1310 nm |
| Maximum transfer distance | 2000 m |
| Features | |
|---|---|
| LED indicators | Yes |
| Product colour | Grey |
| DIN rail mounting | Yes |
| Internal | No |
| Ports & interfaces | |
|---|---|
| Fiber optic connector | LC |
| Fiber ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Weight & dimensions | |
|---|---|
| Height | 21.6 mm |
| Depth | 91.4 mm |
| Width | 31.8 mm |
| Operational conditions | |
|---|---|
| Operating altitude | 0 - 3048 m |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -15 - 65 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Certificates | |
|---|---|
| Compliance certificates | RoHS |
