£1,004.99

Stock Available: 7
  • Multi-Gigabit supports with 2.5G and 10G combinations offering flexibility for high density Multi-Gig deployments
  • Up to Six 10G uplinks including both copper and fiber options providing extensibility and resilience for networks
  • Main ports support up to 2.5G makes the Switch an ideal solution for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user
  • Nebula ecosystem offers a unified cloud network experience, from wired, wireless and security gateway
  • Smart Managed L2 Switch feature set with L3 static route
  • Access and manage the full feature sets included from the first day of purchase through the local web GUI

The XMG1930 series is a family of Multi-Gigabit L2 Smart Managed switches including 2 models, with and without PoE options.
On top of its high-density twenty-four 2.5G ports that serve as a top performance access switch to upgrade from standard gigabit network, the switches also offer four 10G Multi-Gigabit ports to expand network connection to WiFi 6/6E AP or 10G servers along with two additional 10G fiber ports for extensibility and resilience. The PoE model XMG1930-30HP supports both PoE+ and PoE++ with a large power budget of 700 W offering great flexibility to deploy WiFi 6/6E and WiFi 7 wireless access points; while the non-PoE model XMG1930-30 is ideal for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user.

Management features
MIB support Y
Configuring Location Settings (CLI) Yes
Web-based management Yes
Cloud-managed Yes
Quality of Service (QoS) support Yes
Switch layer L3
Switch type Managed
Ports & interfaces
Power connector AC-in jack
Fiber optic connector SFP+
Installed SFP+ modules quantity 2
10G Ethernet (copper) ports quantity 4
Basic switching RJ-45 Ethernet ports type 2.5G Ethernet (100/1000/2500)
Basic switching RJ-45 Ethernet ports quantity 24
Network
Number of VLANs 4000
VLAN support Yes
Flow control support Yes
Rate limiting Yes
Broadcast storm control Yes
Ethernet LAN data rates 10,100,1000,2500,10000 Mbit/s
Spanning tree protocol Yes
Policy-based routing Yes
10G support Yes
Networking standards IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z
Data transmission
Jumbo frames 12000
Jumbo frames support Yes
Static route Yes
Forwarding rate 178.5 Mpps
Switching capacity 240 Gbit/s
MAC address table 16000 entries
Security
Loop protection Yes
MAC address filtering Yes
SSH/SSL support Yes
IGMP snooping Yes
Access Control List (ACL) Yes
DHCP features DHCP client, DHCPv6 relay
Multicast features
Multicast support Yes
Protocols
GARP VLAN Registration Protocol (GVRP) Yes
Design
LED indicators Yes
Reset button Yes
Product colour Black
Form factor 1U
Rack mounting Yes
Performance
Mean time between failures (MTBF) 587922.31 h
Power
Power consumption (max) 864.1 W
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Power supply included Yes
Power source AC
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 700 W
Power over Ethernet plus (PoE+) ports quantity 20
Power over Ethernet (PoE) ports quantity 28
Power over Ethernet (PoE) Yes
Operational conditions
Heat dissipation 864.1 BTU/h
Storage relative humidity (H-H) 5 - 95%
Operating relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) -20 - 50 °C
Weight & dimensions
Weight 4.85 kg
Height 44 mm
Depth 330 mm
Width 441 mm
Packaging content
Rack mount kit Yes
Cables included AC
