£180,719.99

Stock Available: 0
  • Managed Web-based management SNMP 1, SNMP 3, HTTP, HTTPS, SSH 2, Telnet, CLI
  • Basic switching RJ-45 Ethernet ports quantity: 16
  • 10G support
  • Switching capacity: 768 Gbit/s
  • 2U Rack mounting
  • Power supply included

Today’s IT organizations are under pressure to keep pace with the growing avalanche of data traffic between data centers and the changes driven by virtualized application workloads. Faced with this challenge, coupled with rising Service Level Agreement (SLA) requirements and recovery expectations, enterprise data centers need their disaster recovery plans to enable fast, continuous, and easy access to mission-critical data from anywhere in the world. The HPE Storage SAN Extension Switch B-series SN4000B with Brocade Fabric Vision technology delivers unprecedented performance, continuous availability, and simplified management to handle the unrelenting growth of data traffic between data centers. The HPE Storage SN4000B is a purpose-built data center extension solution that maximizes performance and scalability for large, complex environments, allowing IT organizations to future-proof their storage extension infrastructure by adding more throughput capacity as their needs grow.

What is new supporting point:
Supports Restriction of Hazardous Substances Directive (RoHS) compliant requirements for RoHS 2016.
Twenty-four 16Gbps Fibre Channel ports, sixteen 1/10 Gigabit Ethernet (GbE) ports, and two 40GbE ports.
Addresses growing requirement for high availability/disaster recovery with demands for increased performance/throughput, manageability, and “always on” reliability.
Provides multiple modes to optimize compression ratios for various throughput requirements.
Hardware-based capabilities to optimize data transfers over the IP link.

Management features
Web-based management Yes
Switch type Managed
Ports & interfaces
Fiber optic connector SFP+
Fiber ports quantity 24
QSFP+ module slots quantity 2
Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity 16
Network
Auto-sensing Yes
Ethernet LAN data rates 1000,10000,40000 Mbit/s
10G support Yes
Data transmission
Jumbo frames support Yes
Switching capacity 768 Gbit/s
MAC address table 0 entries
Security
Security algorithms IPSec
Authentication type RADIUS
Protocols
Management protocols SNMP 1, SNMP 3, HTTP, HTTPS, SSH 2, Telnet, CLI
Design
Airflow direction Back-to-front airflow
Product colour Metallic
Form factor 2U
Rack mounting Yes
Power
AC input frequency 47/63 Hz
AC input voltage 85 - 264 V
Number of power supply units 2
Redundant power supply (RPS) support Yes
Power supply included Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating altitude 0 - 3000 m
Storage relative humidity (H-H) 10 - 90%
Operating relative humidity (H-H) 10 - 85%
Storage temperature (T-T) -25 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 19 kg
Height 86 mm
Depth 609 mm
Width 440 mm
