HPE FlexFabric 5930 2-slot 2QSFP+ Front-to-Back AC Bundle Managed L3 1U Grey
£20,347.99
Couldn't load pickup availability
- Managed L3
- Quality of Service (QoS) support
- Console port: RJ-45
- MAC address table: 288000 entries Switching capacity: 1440 Gbit/s
- Access Control List (ACL)
- 1U Rack mounting Stackable
The HPE FlexFabric 5930 Switch Series provides advanced features and high performance in a top-of-rack, data center switch architecture. Consisting of a 1U 32-port 40GbE QSFP+ Switch, a 2-slot modular version with 2 40GbE ports and a 4-slot modular version, the 5930 brings high density to a small footprint.
While 9-unit IRF reduces management complexities by up to 88%, it also delivers
| Management features | |
|---|---|
| Quality of Service (QoS) support | Yes |
| Switch layer | L3 |
| Switch type | Managed |
| Ports & interfaces | |
|---|---|
| Console port | RJ-45 |
| QSFP+ module slots quantity | 2 |
| Network | |
|---|---|
| VLAN support | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| Spanning tree protocol | Yes |
| Routing entries | 128000 |
| Port mirroring | Yes |
| 10G support | No |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah |
| Data transmission | |
|---|---|
| Packet buffer memory | 12.2 MB |
| Jumbo frames support | Yes |
| Latency (10 Gbps) | 1 µs |
| Throughput | 1071 Mpps |
| Switching capacity | 1440 Gbit/s |
| MAC address table | 288000 entries |
| Security | |
|---|---|
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| DHCP features | DHCP server, DHCP client |
| Design | |
|---|---|
| Product colour | Grey |
| Form factor | 1U |
| Stackable | Yes |
| Rack mounting | Yes |
| Performance | |
|---|---|
| Flash memory | 1024 MB |
| Internal memory | 4096 MB |
| Memory type | SDRAM |
| Power | |
|---|---|
| Power consumption (max) | 508 W |
| Power consumption (typical) | 105 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 90 - 264 V |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | No |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 45 °C |
| Weight & dimensions | |
|---|---|
| Weight | 18 kg |
| Height | 44.2 mm |
| Depth | 660 mm |
| Width | 440 mm |
