£227.99

Stock Available: 0
  • Seven advanced smart managed Layer 2+ Gigabit switches for high-performance connectivity
  • Non-PoE and Class 4 PoE (i.e. PoE+) 8-, 24- and 48-port models for deployment flexibility
  • 1G/10G SFP+ ports on 24-and 48-port models for fiber connectivity
  • Aruba Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely
  • Option to manage your switches through local web GUI
  • Limited Lifetime Warranty

The HPE Networking Instant On Switch 1930 series is designed for small and growing businesses that require enhanced performance to support bandwidth-demanding applications. The 1930 switch series seamlessly integrates with existing Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely. These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1 G SFP slots on 8-port model and 1 G/10 G SFP+ slots on 24-/48 G models for fiber connectivity.

What is new supporting point:
Seven advanced smart managed Layer 2+ Gigabit switches for high-performance connectivity.
Non-PoE and Class 4 PoE (i.e. PoE+) 8-, 24- and 48-port models for deployment flexibility.
1 G/10 G SFP+ ports on 24-and 48-port models for fiber connectivity.
HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
Option to manage your switches through local web GUI.

Management features
System event log Yes
ARP inspection Yes
Web-based management Yes
Cloud-managed Yes
Quality of Service (QoS) support Yes
Switch layer L2/L3/L4
Switch type Managed
Ports & interfaces
SFP module slots quantity 2
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 8
Network
Number of VLANs 4093
VLAN support Yes
Link aggregation Yes
Auto-sensing Yes
Flow control support Yes
Active link detection Yes
Rate limiting Yes
Spanning tree protocol Yes
Routing entries 32
IP routing Yes
Full duplex Yes
Port mirroring Yes
10G support No
Data transmission
Packet buffer memory 1.5 MB
Jumbo frames 9216
Jumbo frames support Yes
Latency (1 Gbps) 3 µs
Latency (10-100 Mbps) 5.2 µs
Throughput 14.88 Mpps
Switching capacity 20 Gbit/s
MAC address table 8000 entries
Security
Loop protection Yes
SSH/SSL support Yes
BPDU filtering/protection Yes
IGMP snooping Yes
Access Control List (ACL) Yes
DHCP features DHCP client, DHCP snooping
Multicast features
Multicast support Yes
Design
Product colour White
Form factor 1U
Stackable Yes
Rack mounting Yes
Performance
Fanless Yes
Flash memory 256 MB
Internal memory 512 MB
Memory type SDRAM / Flash
Maximum SPAN sessions 800
Processor model ARM Cortex-A9
Built-in processor Yes
Power
Power consumption (max) 150.2 W
Input current 0.2 A
AC input frequency 50 - 60 Hz
AC input voltage 200 - 240 V
Power supply included Yes
Power source AC
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 124 W
Power over Ethernet (PoE) Yes
Operational conditions
Operating altitude 0 - 3000 m
Storage relative humidity (H-H) 15 - 95%
Operating relative humidity (H-H) 15 - 95%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 1.16 kg
Height 254 mm
Depth 254 mm
Width 43.9 mm
General
Product family Aruba Networking
