£222.99

Stock Available: 0
  • Seven advanced smart managed Layer 2+ Gigabit switches for high-performance connectivity
  • Non-PoE and Class 4 PoE (i.e. PoE+) 8-, 24- and 48-port models for deployment flexibility
  • 1G/10G SFP+ ports on 24-and 48-port models for fiber connectivity
  • Aruba Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely
  • Option to manage your switches through local web GUI
  • Limited Lifetime Warranty

The HPE Networking Instant On Switch 1930 series is designed for small and growing businesses that require enhanced performance to support bandwidth-demanding applications. The 1930 switch series seamlessly integrates with existing Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely. These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1 G SFP slots on 8-port model and 1 G/10 G SFP+ slots on 24-/48 G models for fiber connectivity.

What is new supporting point:
Option to manage your switches through local web GUI.
Seven advanced smart managed Layer 2+ Gigabit switches for high-performance connectivity.
Non-PoE and Class 4 PoE (i.e. PoE+) 8-, 24- and 48-port models for deployment flexibility.
1 G/10 G SFP+ ports on 24-and 48-port models for fiber connectivity.
HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.

Management features
System event log Yes
ARP inspection Yes
Web-based management Yes
Cloud-managed Yes
Quality of Service (QoS) support Yes
Switch layer L2/L3/L4
Switch type Managed
Ports & interfaces
SFP+ module slots quantity 4
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 24
Network
Number of VLANs 4093
VLAN support Yes
Link aggregation Yes
Auto-sensing Yes
Flow control support Yes
Active link detection Yes
Rate limiting Yes
Ethernet LAN data rates 10,1000,100 Mbit/s
Spanning tree protocol Yes
Routing entries 32
IP routing Yes
Full duplex Yes
Port mirroring Yes
Copper ethernet cabling technology 1000BASE-T
10G support No
Data transmission
Packet buffer memory 1.5 MB
Jumbo frames 9216
Jumbo frames support Yes
Latency (10 Gbps) 1.3 µs
Latency (1 Gbps) 2.4 µs
Latency (10-100 Mbps) 4.7 µs
Throughput 95.23 Mpps
Switching capacity 128 Gbit/s
MAC address table 16000 entries
Security
Loop protection Yes
SSH/SSL support Yes
BPDU filtering/protection Yes
IGMP snooping Yes
Access Control List (ACL) Yes
DHCP features DHCP client, DHCP snooping
Multicast features
Multicast support Yes
Design
Product colour White
Form factor 1U
Stackable Yes
Rack mounting Yes
Performance
Fanless Yes
Flash memory 256 MB
Internal memory 512 MB
Memory type SDRAM / Flash
Processor frequency 800 MHz
Processor model ARM Cortex-A9
Built-in processor Yes
Power
Power consumption (max) 22.6 W
Input current 0.2 A
AC input frequency 50 - 60 Hz
AC input voltage 200 - 240 V
Power supply included Yes
Power source AC
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating altitude 0 - 3000 m
Storage relative humidity (H-H) 15 - 95%
Operating relative humidity (H-H) 15 - 95%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 2.41 kg
Height 221.5 mm
Depth 442.5 mm
Width 43.9 mm
General
Product family Aruba Networking
