Cisco Nexus 5596UP, Refurbished Managed L2/L3 10G Ethernet (100/1000/10000) 2U Silver
Couldn't load pickup availability
- Managed L2/L3 SSHv2, Telnet, RADIUS, TACACS+, SNMP, RMON, RBAC, NTP
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 48
- 10G support 10BASE-T, 100BASE-TX, 1000BASE-TX
- MAC address table: 32000 entries
- Access Control List (ACL)
- 2U Rack mounting
- Power supply included
The Cisco Nexus 5500 platform is equipped with expansion modules that can be used to increase the number of 10 Gigabit Ethernet and FCoE ports or to connect to Fibre Channel SANs with 8/4/2/1-Gbps Fibre Channel switch ports, or both.
The Cisco Nexus 5548P and 5548UP supports one expansion module, and 5596UP supports three expansion modules from the following offerings
- Ethernet module that provides sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface
- Fibre Channel plus Ethernet module that provides eight 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface, and eight ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+/SFP interface
- A unified port module that provides up to sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface or up to sixteen ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+ and SFP interface. The use of 1/10 Gigabit Ethernet or 8/4/2/1-Gbps Fibre Channel on a port is mutually exclusive but selectable for any of the 16 physical ports per module.
| Management features | |
|---|---|
| MIB support | Y |
| ARP inspection | Yes |
| Quality of Service (QoS) support | Yes |
| Switch layer | L2/L3 |
| Switch type | Managed |
| Ports & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Network | |
|---|---|
| VLAN support | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-TX |
| 10G support | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x |
| Data transmission | |
|---|---|
| Jumbo frames | 9216 |
| Jumbo frames support | Yes |
| MAC address table | 32000 entries |
| Security | |
|---|---|
| Security algorithms | 802.1x RADIUS, AES |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| DHCP features | DHCP server, DHCP client |
| Multicast features | |
|---|---|
| Multicast support | Yes |
| Protocols | |
|---|---|
| Switching protocols | EIGRP, OSPFv2, BGP, HSRP, VRRP, PIMv2, MSDP, IGMPv2/v3 |
| Management protocols | SSHv2, Telnet, RADIUS, TACACS+, SNMP, RMON, RBAC, NTP |
| Design | |
|---|---|
| Electromagnetic compatibility | 47CFR, AS/NZS CISPR22, CISPR22, EN55022, ICES003, VCCI |
| Safety | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, AS/NZS 609, GB49430-1 |
| LED indicators | Yes |
| Product colour | Silver |
| Form factor | 2U |
| Stackable | No |
| Rack mounting | Yes |
| Performance | |
|---|---|
| Expansion module support | Yes |
| Power | |
|---|---|
| Power consumption (max) | 882 W |
| Power consumption (typical) | 680 W |
| Output power | 2200 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Number of power supply units | 2 |
| Power supply included | Yes |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | No |
| Operational conditions | |
|---|---|
| Heat dissipation | 1331 BTU/h |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 21.6 kg |
| Height | 88 mm |
| Depth | 749 mm |
| Width | 439 mm |
| General | |
|---|---|
| Product family | Nexus |
