AOC AS110DX monitor mount / stand 81.3 cm (32") Desk Black
Couldn't load pickup availability
- USB 3.0 Hub
- Gas Spring
- VESA 75x75mm, 100x100mm
- Weight capacity range (each arm) 2 - 9 Kg
Get your monitor in the optimum position easily with AS110's mechanical gas-spring arm with integrated USB Hub
AS110's sleek and sturdy, gas-spring controlled monitor arm enables wide range of ergonomics for your VESA (75 mm or 100 mm) supported monitor. Free up your desk with integrated cable management. Supports up to 32", 9 kg monitors and offers 320 mm height, 325 mm stretch, -45°/60° tilt, -90°/90° swivel and 360° pivot range for increased flexibility. Built in USB Hub provides an easy way to transmit data & charge your devices. The USB Hub is equipped with a USB 3.0 port supporting data transfer speed up to 5Gbps and a USB-C port supporting data transfer speed up to 5Gbps allowing you to transfer your favorite content & files in seconds. Use the integrated USB 3.0 male extension cords to connect your PC with the USB Hub, and boost your productivity with a clutter-free desk.
| Mounting | |
|---|---|
| Mounting hole range | 7 - 87 mm |
| Grommet mount desk thickness (max) | 8 cm |
| Clamp mount desk thickness (max) | 8 cm |
| Desk thickness (max) | 8 cm |
| Desk thickness (min) | 1.5 cm |
| Number of displays supported | 1 |
| Panel mounting interface | 100 x 100,75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Minimum VESA mount | 75 x 75 mm |
| Mounting | Clamp/Bolt-through |
| Maximum weight capacity (per display) | 9 kg |
| Mounting type | Desk |
| Maximum screen size | 81.3 cm (32") |
| Minimum screen size | 33 cm (13") |
| Maximum weight capacity | 9 kg |
| Ergonomics | |
|---|---|
| Cable management | Yes |
| Pivot angle | 0 - 360° |
| Rotating | Yes |
| Swivel angle range | -90 - 90° |
| Swivelling | Yes |
| Tilt angle range | -45 - 60° |
| Tilt adjustment | Yes |
| Depth adjustment range | 0 - 460 mm |
| Height adjustment range | 320 - 440 mm |
| Height adjustment type | Gas spring |
| Height adjustment | Yes |
| Design | |
|---|---|
| Housing material | Aluminium |
| Product colour | Black |
| Ports & interfaces | |
|---|---|
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| Built-in USB hub | Yes |
| Weight & dimensions | |
|---|---|
| Weight | 2.65 kg |
| Packaging data | |
|---|---|
| Package weight | 2.9 kg |
| Package height | 120 mm |
| Package depth | 410 mm |
| Package width | 280 mm |
| Packaging content | |
|---|---|
| Packaging content | User Manual, Monitor Arm, Clamp mount, Grommet mount, Installation materials |
| Manual | Yes |
| Mounting kit | Yes |
| Clamp included | Yes |
| Other features | |
|---|---|
| Warranty period | 5 year(s) |
| Height (max) | 58 cm |
