APC SRV3KI uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2400 W 6 AC outlet(s)
Couldn't load pickup availability
- Double-conversion (Online)
- 3 kVA 2400 W
- 6 AC outlet(s)
- 12 V 9 Ah
- Mini Tower Black
APC Easy UPS SRV 3000VA 230V
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.
Serial connectivity
Provides management of the UPS via a serial port.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
| Features | |
|---|---|
| Socket circuit breaker | Yes |
| Emergency Power Off (EPO) | No |
| Crest factor | 3:1 |
| Efficiency | 88% |
| Surge energy rating | 600 J |
| Output operation voltage (max) | 240 V |
| Output operation voltage (min) | 220 V |
| Input frequency | 40 - 70 Hz |
| Input operation voltage (max) | 285 V |
| Input operation voltage (min) | 110 V |
| Output power | 2400 W |
| Output power capacity | 3 kVA |
| UPS topology | Double-conversion (Online) |
| Ports & interfaces | |
|---|---|
| RS-232 ports | 1 |
| Serial interface type | RS-232 |
| Serial interface | Yes |
| USB 2.0 ports quantity | 1 |
| USB port | Yes |
| AC outlets quantity | 6 AC outlet(s) |
| Power plug | C19 coupler |
| AC outlet types | C13 coupler |
| Battery | |
|---|---|
| Battery recharge time | 4 h |
| Number of batteries supported | 1 |
| Battery voltage | 12 V |
| Battery capacity | 48 VAh |
| Design | |
|---|---|
| Display type | LCD |
| Product colour | Black |
| Form factor | Mini Tower |
| Operational conditions | |
|---|---|
| Non-operating altitude | 0 - 15000 m |
| Operating altitude | 0 - 3000 m |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -20 - 50 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Packaging content | |
|---|---|
| Manual | Yes |
| Cables included | Input power cable, Output power cable, RS-232, USB cable |
| Weight & dimensions | |
|---|---|
| Weight | 26.8 kg |
| Height | 336 mm |
| Depth | 425 mm |
| Width | 190 mm |
| Packaging data | |
|---|---|
| Package weight | 29 kg |
| Package height | 465 mm |
| Package depth | 565 mm |
| Package width | 325 mm |
| Warranty card | Yes |
| Software CD | Yes |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85078000 |
