Lenovo 4XB7A82852 internal solid state drive 3.84 TB M.2 PCI Express 4.0 NVMe 3D TLC NAND
Couldn't load pickup availability
- 3.84 TB M.2 PCI Express 4.0
- 735000 IOPS
- 160000 IOPS
- 3D TLC NAND NVMe
- Hardware encryption
- S.M.A.R.T. support ECC
- Component for: Server/workstation
The ThinkSystem 7450 PRO Read Intensive NVMe SSDs are general-purpose yet high-performance family of NVMe solid-state drives. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.
This product guide provides essential presales information to understand the ThinkSystem 7450 PRO Read Intensive NVMe SSDs offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the 7450 PRO SSDs and consider their use in IT solutions.
| Features | |
|---|---|
| Certification | CE (Europe): EN55032, EN55024 Class B, RoHSFCC: CFR Title 47, Part 15, Class BUL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013BSMI (Taiwan): approval to CNS 13438, Class B, CNS 15663RCM (Australia, New Zealand): AS/NZS CISPR32 Class BKC RRL (Korea): approval to KN32 Class B, KN 35 Class BW.E.E.E.: Compliance with EU WEEE directive 2012/19/EC.TUV (Germany): approval to IEC60950/EN60950VCCI (Japan): 2015-04 Class BIC (Canada): ICES-003 Class BMorocco: EN55032, EN55024 Class BUkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139)UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS |
| Mean time between failures (MTBF) | 2000000 h |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| ECC | Yes |
| S.M.A.R.T. support | Yes |
| Write latency | 15 µs |
| Read latency | 80 µs |
| Random write (4KB) | 160000 IOPS |
| Random read (4KB) | 735000 IOPS |
| Hardware encryption | Yes |
| Component for | Server/workstation |
| Memory type | 3D TLC NAND |
| NVMe | Yes |
| Interface | PCI Express 4.0 |
| SSD form factor | M.2 |
| SSD capacity | 3.84 TB |
| Power | |
|---|---|
| Power consumption (write) | 8.2 W |
| Power consumption (read) | 8.2 W |
| Weight & dimensions | |
|---|---|
| Weight | 70 g |
| Depth | 100 mm |
| Width | 70 mm |
| Operational conditions | |
|---|---|
| Maximum operating altitude | 3050 m |
| Non-operating shock | 1500 G |
| Non-operating vibration | 20 G |
| Storage relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating temperature (T-T) | 0 - 70 °C |
