ATEN USB 2.0 DVI Single Link over 1 CAT Cable (100m) KVM Extender with Full USB2.0 support (up to 480Mbps) / HDBaseT2.0
£624.99
Couldn't load pickup availability
- HDBaseT™ 2.0 connectivity technology
- • Extends video, audio, USB and RS-232 signals via a single Ethernet cable
- • EDID Buffer for smooth power-up and the highest quality display
- • Enhanced bit error detection and correction to resist signal interference during high-quality video transmissions
- Long distance superior video quality
- • HDBaseT™ Standard mode up to 1920 x 1200 @ 100 m
- • HDBaseT™ Long Reach mode up to 1920 x 1080 @ 150 m
- Long Reach mode switch — switches between HDBaseT™ Standard and Long Reach modes in a snap
- 3 USB 2.0 ports for keyboard/mouse and peripherals
- Supports 2-channel PCM digital audio — ensuring highquality audio transmissions
- Supports PC Wakeup function via pushbutton or hotkey
- Built-in 8KV/15KV ESD pr otection (Contact voltage 8KV; Air voltage 15KV)
- Note: The CE620 does not support HDCP.
The ATEN CE620 USB DVI HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to provide the most reliable transmission of video, audio, USB and RS-232 signals available on the market. Featured with a Long Reach mode, the CE620 delivers high-quality DVI video, PCM 2-channel digital audio, USB 2.0, and RS-232 signals up to 150 meters using a single Cat6/6a/ATEN 2L-2910 Cat 6 cable. With a simple cable installation supporting various signals, the CE620 is ideal for applications where convenient remote access is required – in places such as transportation control centers, medical facilities, industrial warehouses and extended workstations.
| Features | |
|---|---|
| Material | Metal |
| Product colour | Black |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum transfer distance | 100 m |
| Connectivity technology | Wired |
| Type | Transmitter & receiver |
| Transmitter | |
|---|---|
| Transmitter local video port type | DVI-D |
| Transmitter local video port | Yes |
| Receiver | |
|---|---|
| Receiver local video port type | DVI-D |
| Power | |
|---|---|
| Power consumption (receiver) (max) | 5.6 W |
| Power consumption (transmitter) (max) | 3 W |
| Weight & dimensions | |
|---|---|
| Receiver weight | 640 g |
| Receiver height | 2.87 cm |
| Receiver depth | 12.3 cm |
| Receiver width | 18.2 cm |
| Transmitter weight | 630 g |
| Transmitter height | 2.87 cm |
| Transmitter depth | 12.3 cm |
| Transmitter width | 18.2 cm |
| Packaging content | |
|---|---|
| Manual | Yes |
| Cables included | DVI |
| AC adapter included | Yes |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Other features | |
|---|---|
| Firmware upgradeable | Yes |
