£2,850.99

Stock Available: 0
  • 100,1000 Mbit/s
  • Power over Ethernet (PoE) VLAN support
  • Rack mounting
  • Black

HPE Aruba Networking 9000 Series Branch Gateways provide high-performance networking, SD-WAN and security functionality in compact and cost-effective form factors. Ideally suited for branch and small campus networks, the 9000 series can be used as a wireless gateway for enhanced Wi-Fi scalability and security or for SD-WAN capabilities in the branch. Deploying this series as part of the HPE Aruba Networking SD-Branch solution is an affordable way to support multiple WAN connections, including the internet, MPLS, cellular, role-based policy enforcement, and path optimization. Designed with enterprise-grade capabilities and compact form factors, including an integrated LTE option, the 9000 Gateway can be easily configured and managed using HPE Aruba Networking Central, an AI-powered solution that simplifies IT operations, improves agility, and reduces costs by unifying management of all network infrastructure.

What is new supporting point:
Versatile cloud-managed edge appliance can be deployed as an SD-Branch gateway or as a wireless gateway for greater scalability.
The gateway provides connectivity for up to 2,048 users or client devices with up to 6 Gbps of firewall throughput.
Layer 4-7 stateful firewall delivers a consistent user, device, and application awareness across WLAN, LAN, and WAN.
Dynamic Segmentation for automated role-based policy enforcement across users, devices, and IoT.
The 9004-LTE model provides integrated LTE connectivity for use as a dedicated or redundant WLAN uplink.

Design
LED indicators LAN, Status, System, WAN
Mounting type Rack mounting
Rack capacity 1U
Product colour Black
Performance
Control display unit No
Protocols
DHCP client Yes
Network
Firewall throughput 6000 Mbit/s
3DES/AES throughput 6 Gbit/s
Number of concurrent sessions (max) 2048
Ethernet LAN data rates 100,1000 Mbit/s
Security
VLAN support Yes
Access Control List (ACL) Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 12
Number of console ports 2
Console port micro USB, RJ-45
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Power
Power over Ethernet (PoE) Yes
Input frequency 47 - 63 Hz
Input voltage 90 - 264 V
Power consumption (max) 160 W
Weight & dimensions
Weight 3.42 kg
Width 43.7 mm
Depth 260 mm
Height 43.7 mm
Operational conditions
Storage relative humidity (H-H) 10 - 95%
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Certificates
Certification None
