Ubiquiti Wave AP Gen2 Network bridge White
iFrame
£553.99
Couldn't load pickup availability
- Network bridge 6000 m
- Wi-Fi Wi-Fi 6 (802.11ax)
- Ethernet LAN 2.5 Gigabit Ethernet
- Aluminium, Polycarbonate (PC) IPX6
- RP-SMA 20 dBi
- White
60 GHz + 5 GHz multipoint base station featuring 90-degree sectoral coverage, 31-client capacity, 2.7 Gbps symmetrical speed, and antenna connectors for 5 GHz range extension.
| Data transmission | |
|---|---|
| Maximum transfer distance | 6000 m |
| Antenna | |
|---|---|
| Antenna gain level (max) | 20 dBi |
| Antenna connector type | RP-SMA |
| Wireless LAN features | |
|---|---|
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK |
| Frequency band | 57 - 71 GHz |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Network | |
|---|---|
| Number of users | 31 user(s) |
| Ethernet LAN data rates | 10,1000,2500 Mbit/s |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ports & interfaces | |
|---|---|
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired & Wireless |
| Security | |
|---|---|
| Security algorithms | AES, SNMP, WPA2-PSK |
| Features | |
|---|---|
| Internal memory | 512 MB |
| Processor frequency | 1.4 MHz |
| Network Time Protocol (NTP) client | Yes |
| Reset button | Yes |
| International Protection (IP) code | IPX6 |
| LED indicators | GPS, LAN, Power |
| Product colour | White |
| Mounting type | Pole |
| Material | Aluminium, Polycarbonate (PC) |
| Product type | Network bridge |
| Power | |
|---|---|
| Power over Ethernet (PoE) voltage | 48 V |
| Power over Ethernet (PoE) | Yes |
| Power consumption (max) | 24 W |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 60 °C |
| Certificates | |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Weight & dimensions | |
|---|---|
| Weight | 1.5 kg |
| Height | 286.8 mm |
| Depth | 100.2 mm |
| Width | 158.3 mm |
| Packaging content | |
|---|---|
| Power supply included | Yes |
| Packaging data | |
|---|---|
| Quantity per pack | 1 pc(s) |
