Seasonic
£84.99
Stock Available: 0
  • 650 W 100 - 240 V 50/60 Hz
  • PC ATX 80 PLUS Gold
  • Active 12 cm
  • Black

The G12 GC Series is available in the standard ATX Form Factor and in wattages that are most common for a PC system. The Seasonic G12 GC-Series achieves 80 PLUS® Gold standard of providing at least 87 %, 90 % and 87 % power usage efficiency at 20 %, 50 % and 100 % operating loads, respectively. This efficiency, combined with Active Power Factor Correction, enables the G12 GC series power supplies to lessen energy waste, which translates into savings on the costs of energy costs for its users. In addition to being greatly efficient, the G12 GC units utilize the LLC resonant converter design, and the industry’s leading Smart and Silent Fan Control (S2FC).

Power
Power protection features Over current, Over power, Under voltage, Over total voltage, Over voltage, Short circuit
Efficiency 90%
Max output current (+5Vsb) 2.5 A
Max output current (-12V) 0.3 A
Max output current (+12V) 54 A
Max output current (+3.3V) 20 A
Combined power (+5Vsb) 12.5 W
Combined power (-12V) 3.6 W
Combined power (+12V) 648 W
Combined power (+3.3V) 100 W
Input current 8 A
AC input frequency 50/60 Hz
AC input voltage 100 - 240 V
Total power 650 W
Ports & interfaces
Cabling type Non-Modular
Performance
Mean time between failures (MTBF) 100000 h
80 PLUS certification 80 PLUS Gold
Power supply unit (PSU) form factor ATX
Purpose PC
Design
On/off switch Yes
Number of fans 1 fan(s)
Fan diameter 12 cm
Cooling type Active
Product colour Black
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Certificates
Certification cTUVus, TUV, CB, CCC, BSMI, CE, FCC
Compliance certificates REACH, RoHS, WEEE
Packaging content
Cables included AC, CPU, PCIe, SATA
Weight & dimensions
Height 86 mm
Depth 140 mm
Width 150 mm
Packaging data
Package type Box
