ASUS TUF Gaming F15 FX507ZV4-LP001W Intel® Core™ i7 i7-12700H Laptop 39.6 cm (15.6") Full HD 16 GB DDR4-SDRAM 512 GB SSD NVIDIA GeForce RTX 4060 Wi-Fi 6 (802.11ax) Windows 11 Home Grey
£1,275.99
Couldn't load pickup availability
- Windows 11 Home 64-bit
- Intel Core i7-12700H (24MB Cache)
- 39.6 cm (15.6") Full HD 1920 x 1080 IPS, NVIDIA GeForce RTX 4060 (8GB GDDR6)
- 16GB (3200MHz) DDR4-SDRAM (2 x 8) & 512GB SSD
Mechanized endurance. Battlefield brilliance.
DESIGN
BRAND NEW DESIGN
The chassis has been redesigned for 2023, now 4.5% smaller than the previous design. The two color options each have a different logo location, with the Jaeger Gray edition featuring a large laser-sculpted design, and the Mecha Gray edition showing off an embossed logo on the lid. The four-way indicators can be seen even while the clamshell is closed, and the touchpad features a mech-inspired TUF logo in the corner.
| Design | |
|---|---|
| Market positioning | Gaming |
| Form factor | Clamshell |
| Colour name | Mecha Gray |
| Product colour | Grey |
| Product type | Laptop |
| Display | |
|---|---|
| Maximum refresh rate | 144 Hz |
| RGB colour space | sRGB |
| Colour gamut | 100% |
| Anti-glare screen | Yes |
| Native aspect ratio | 16:9 |
| Panel type | IPS |
| HD type | Full HD |
| Touchscreen | No |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 39.6 cm (15.6") |
| Processor | |
|---|---|
| Configurable TDP-down | 35 W |
| Processor cache | 24 MB |
| Processor boost frequency | 4.7 GHz |
| Processor cores | 14 |
| Processor model | i7-12700H |
| Processor generation | 12th gen Intel® Core™ i7 |
| Processor family | Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 32 GB |
| Memory slots | 2x SO-DIMM |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory clock speed | 3200 MHz |
| Memory form factor | SO-DIMM |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| SSD form factor | M.2 |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD capacity | 512 GB |
| Number of SSDs installed | 1 |
| Total SSDs capacity | 512 GB |
| Storage media | SSD |
| Total storage capacity | 512 GB |
| Graphics | |
|---|---|
| NVIDIA G-SYNC | Yes |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board GPU manufacturer | Intel |
| Discrete graphics memory type | GDDR6 |
| Discrete graphics card memory | 8 GB |
| Discrete graphics card model | NVIDIA GeForce RTX 4060 |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card | Yes |
| On-board graphics card | Yes |
| Audio | |
|---|---|
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | Dolby Atmos |
| Camera | |
|---|---|
| Front camera resolution | 1280 x 720 pixels |
| Front camera HD type | HD |
| Front camera | Yes |
| Network | |
|---|---|
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN | Yes |
| Antenna type | 2x2 |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Mobile network connection | No |
| Ports & interfaces | |
|---|---|
| USB Type-C DisplayPort Alternate Mode | Yes |
| Combo headphone/mic port | Yes |
| Intel® Thunderbolt 4 | Yes |
| Thunderbolt 4 ports quantity | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Keyboard | |
|---|---|
| Keyboard backlit colour | RGB |
| Numeric keypad | Yes |
| Keyboard backlit | Yes |
| Pointing device | Touchpad |
| Software | |
|---|---|
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Home |
| Processor special features | |
|---|---|
| CPU configuration (max) | 1 |
| Battery | |
|---|---|
| Battery capacity | 90 Wh |
| Number of battery cells | 4 |
| Battery technology | Lithium-Ion (Li-Ion) |
| Power | |
|---|---|
| USB Power Delivery (USB PD) | Yes |
| DC-in jack | Yes |
| AC adapter output voltage | 20 V |
| AC adapter output current | 12 A |
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter power | 240 W |
| Security | |
|---|---|
| Password protection type | BIOS, User |
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Sustainability | |
|---|---|
| Sustainability certificates | EPEAT Bronze, ENERGY STAR |
| Weight & dimensions | |
|---|---|
| Height (rear) | 2.49 cm |
| Height (front) | 2.24 cm |
| Depth | 251 mm |
| Width | 354 mm |
| Weight | 2.2 kg |
| General | |
|---|---|
| Product family | TUF Gaming |
| Product series | F15 |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
