StarTech.com 2 Port Triple Monitor DVI USB KVM Switch with Audio & USB 2.0 Hub
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £52.66 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Black
- Number of computers controlled: 2
- Keyboard port type: USB Mouse port type: USB Video port type: DVI-I
- 1920 x 1200 pixels
- Hot keys
- 18 W External power adapter
The SV231TDVIUA 2-Port Triple Monitor DVI USB KVM Switch allows 2 PCs (each with 3 DVI video outputs) to share monitors, 1 microphone and set of speakers, 1 keyboard and 1 mouse, as well as an additional USB 2.0 peripheral such as an external hard drive, thumb drive, printer, or webcam.
The Triple DVI KVM switch enables you to switch back and forth between 2 multi DVI PCs at the touch of a button, while maintaining professional-level video quality on all monitors at resolutions up to 1920x1200. The triple monitor DVI switch also features an integrated USB hub port which allows USB 2.0 peripherals to be shared between attached systems, eliminating duplicate peripheral costs and offering the convenience of sharing stored data between PCs.
The SV231TDVIUA 2-Port Triple Head DVI KVM Switch is backed by a StarTech.com 3-year warranty and free lifetime technical support.
PLEASE NOTE: While the DVI connector on this KVM is DVI-I, the KVM only supports single-link DVI-D (digital only) video sources. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to console connections.
The StarTech.com Advantage
- By enabling control of two triple display computer systems using a single set of peripherals, the switch helps saves cost and work space
- With support for high definition resolutions (1920x1200) on each of the 3 connected monitors, the triple head KVM switch offers maximum screen real estate for optimized productivity
- Integrated USB 2.0 hub and mic/audio ports enable you to have full multimedia control of two computers, while sharing USB peripherals
Specifications
Ports & interfaces
| DC-in jack | Yes |
|---|---|
| Number of microphone inputs | 2 |
| Headphone outputs | 2 |
| Audio connections | Yes |
| USB 2.0 ports quantity | 2 |
| Console ports | DVI-I, 3.5mm headphone, 3.5mm mic, USB A |
| Console USB ports quantity | 4 |
| DVI-I ports quantity | 6 |
| Video port type | DVI-I |
| Mouse port type | USB |
| Keyboard port type | USB |
| Number of computers controlled | 2 |
Performance
| Number of users | 1 user(s) |
|---|---|
| Daisy chain | No |
| Plug and Play | Yes |
| HDCP | Yes |
| Scan interval | 3,8,15,30 s |
| Maximum digital resolution | 1920 x 1200 pixels |
| Maximum resolution | 1920 x 1200 pixels |
Show all 47 specificationsShow fewer specifications
Design
| Certification | CE, FCC |
|---|---|
| Mean time between failures (MTBF) | 62000 h |
| Hot keys | Yes |
| LED indicators | Activity |
| Product colour | Black |
| Rack mounting | No |
Display
| On Screen Display (OSD) | No |
|---|---|
| Built-in display | No |
Power
| Power consumption (typical) | 18 W |
|---|---|
| External power adapter | Yes |
| Power plug type | Type M |
| Output current | 1.5 A |
| Output voltage | 12 V |
| Input current | 0.8 A |
| Input voltage | 110-240 V |
Sustainability
| Compliance certificates | RoHS |
|---|
Operational conditions
| Operating relative humidity (H-H) | 0 - 80% |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Weight | 900 g |
|---|---|
| Height | 74 mm |
| Depth | 100 mm |
| Width | 159 mm |
Packaging content
| Rubber feet | Yes |
|---|---|
| Manual | Yes |
| AC adapter included | Yes |
Other features
| Audio support | Yes |
|---|---|
| IP control | No |
