Intel Core i7-14700 processor 33 MB Smart Cache Tray
Intel Core i7-14700 processor 33 MB Smart Cache Tray

Intel Core i7-14700 processor 33 MB Smart Cache Tray

Intel · MPN: CM8071504820817
£341.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £113.99 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview
  • Intel® Core™ i7 i7-14700
  • 33 MB Smart Cache LGA 1700
  • Processor cores: 20 64-bit
  • Maximum internal memory supported by processor: 192 GB DDR4-SDRAM, DDR5-SDRAM
  • On-board graphics card Intel UHD Graphics 770
  • Tray

Specifications

Processor

Processor ARK ID236781
Processor codenameRaptor Lake
Memory bandwidth supported by processor (max)89.6 GB/s
Maximum number of DMI lanes8
SteppingB0
Processor base power65 W
Maximum turbo power219 W
Processor cache typeSmart Cache
Processor cache33 MB
Efficient-core base frequency1.5 GHz
Efficient-core boost frequency4.2 GHz
Performance-core base frequency2.1 GHz
Performance-core boost frequency5.3 GHz
Processor boost frequency5.4 GHz
Efficient cores12
Performance cores8
Processor operating modes64-bit
Processor threads28
Processor socketLGA 1700
Processor cores20
Processor modeli7-14700
Processor generationIntel® Core™ i7 (14th gen)
Processor familyIntel® Core™ i7
Processor manufacturerIntel

Memory

Memory bandwidth (max)89.6 GB/s
ECCYes
Memory channelsDual-channel
Memory types supported by processorDDR4-SDRAM, DDR5-SDRAM
Maximum internal memory supported by processor192 GB
Show all 96 specificationsShow fewer specifications

Graphics

Multi-Format Codec Engines2
Number of execution units32
Discrete graphics card modelNot available
On-board graphics card ID0xA780
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card maximum resolution (DisplayPort)7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI)4096 x 2160 pixels
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
Number of displays supported (on-board graphics)4
On-board graphics card dynamic frequency (max)1600 MHz
On-board graphics card base frequency300 MHz
On-board graphics card outputs supportedEmbedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card modelIntel UHD Graphics 770
On-board graphics cardYes
Discrete graphics cardNo

Features

Commodity Classification Automated Tracking System (CCATS)740.17B1
Export Control Classification Number (ECCN)5A992C
Scalability1S
Embedded options availableYes
Direct Media Interface (DMI) Revision4.0
CPU configuration (max)1
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
PCI Express configurations1x16+1x4, 2x8+1x4
PCI Express slots version4.0, 5.0
Maximum number of PCI Express lanes20
Use conditionsWorkstation, PC/Client/Tablet
Market segmentDesktop
Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes

Processor special features

Intel VT-x with Extended Page Tables (EPT)Yes
Intel 64Yes
Intel® Standard Manageability (ISM)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Volume Management Device (VMD)Yes
Mode-based Execute Control (MBE)Yes
Intel® Secure KeyYes
Intel® OS GuardYes
Intel Turbo Boost Max Technology 3.0Yes
Intel® Boot GuardYes
Intel® Thread DirectorYes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0Yes
Intel® Turbo Boost Max Technology 3.0 frequency5.4 GHz
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Speed Shift TechnologyYes
Intel® Quick Sync Video TechnologyYes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Enhanced Intel SpeedStep TechnologyYes

Operational conditions

Tjunction100 °C

General

Product familyCore
Product seriesi7

Technical details

Launch dateQ1'24
StatusLaunched
OpenCL version3.0

Weight & dimensions

Processor package size45 x 37.5 mm

Other features

Graphics outputeDP 1.4b, DP 1.4a, HDMI 2.1
Maximum internal memory192 GB
L2 cache28672 KB
